Selene Ocean Trawlers

Denison Yacht Sales is the exclusive dealer for Selene Ocean Trawlers for the Southeast United States.

Selene Yachts Specialist: Yacht Broker Kevin Frawley – 954.790.0372

About Selene Trawlers

Established: 1998
Located: China
Construction: Fiberglass
Category: Trawlers, Full-Displacement

“Grace and Strength” is not just a slogan for Selene Yachts, it is backed up by a rigorous commitment to quality and a dedication to continuous improvement. Every Selene Yacht is built from the highest quality materials. Each hull is constructed using Cook Gelcoat and Vinylester resin to prolong the beauty and resist moisture absorption. Cymax unidirectional bi-axial fiberglass is used for structural integrity. Above the waterline, balsa core is used for light weight strength, stability and insulation. Vacuum bagging insures a solid bond between core and laminate materials. Gelcoat is applied using the state of the art MVP airless spray system for flawless application.

While high-quality materials and components are critical, even the best materials can be wasted if manufacturing processes are not consistently controlled. A key part of Jet Tern Marine’s commitment to quality is achieving ISO 9001 certification. ABS Quality Evaluations, Inc. awarded Jet Tern Marine with ISO 9001 certification in August 2001 (Certificate number 35916). This certification means that Selene’s processes are documented and controlled to insure consistency, which is an important part of quality. Jet Tern Marine is the first shipyard in China producing yachts to achieve ISO certification.

Selene Commissioning

New Selene Ocean Trawler are commissioned at the Selene Florida Service Center, located at Apex Marine in downtown Fort Lauderdale, Florida. Upon arrival stateside your Selene Trawler is first inspected in the greatest detail using the same 500-item checklist plus a rigorous visual inspection to assure that every specification you have defined is met, and every system and factory-installed piece of equipment is fully and dependably operational.

Over 20 pages of detailed CAD drawings shipped with your Selene document all her systems her as built. These are verified upon arrival inspection in the yard.

Typically owners contract separately with the commissioning yard to acquire and install things like the electronics, entertainment technology, the tender, ground tackle, canvas, etc.

We will want to test your Selene and all her systems in a real environment. How do the stabilizers work? Are there any leaks? How is the engine doing? If you have a get-home, it is tested, too. Sometimes we discover things that need adjustment or correction. They are noted. Back in the commissioning yard, each issue is assigned to the specialist responsible to resolve it.

Upon demonstration that all of the vessel’s basic systems and operations are satisfactory, the vessel is accepted and title passes to the owner. Things that are added to the boat at the commissioning yard (i.e. electronics, tender), unless part of the original Purchase Agreement, are arranged between the owner and the yard, and are accepted independent of vessel acceptance.

Selene Florida and Denison Yacht Sales are here to support you long after delivery. At any time, we can be tapped for a prompt, efficient follow-up on a range of issues. Need a spare part? Questions on how this or that should work? Has something failed a couple years down the road and you need a recommendation for a repair? We are here to help.

About Jet-Tern Marine

Jet-Tern Marine is one of a group of companies in the Jet-Tern Group owned by the Chen Family. Howard Chen, founder of Jet Tern Marine, is a graduate of the Taiwan National Cheng Kung University with a Bachelor’s Degree in Naval Architecture and Marine Engineering. In addition, Chen has a Master’s degree in architecture from Taiwan Tunghai University.

After serving in the R.O.C. army and working as an engineer at another yacht design firm, Howard established Jet Tern Marine in 1998. The first Selene Trawler arrived in the US in 1999. Today, more than 225 Selene Yachts are cruising the world.

Selene Yachts are manufactured in state of the art facilities in Dongguan, and Zhuhai, cities in Canton, China, not far from Hong Kong. Selene hulls are laminated using a female mold. Because the hulls are built from the “outside in” one of the first steps is applying the gelcoat which will be the glossy outer finish of the hull. Gelcoat is applied using a state of the art MVP airless spray system that ensures consistent, even film thickness and avoids “print through” (where the underlying fiberglass shows through the outer layer of gelcoat).

Successive layers of fiberglass cloth soaked in resin are applied to the inside of the mold over the gelcoat. The number of layers of cloth and the type of cloth are carefully specified and controlled to produce a consistently strong hull. Once the hull is complete, it is removed from the mold by separating the mold into two halves at the centerline of the hull. The interior components and machinery are then installed in the completed hull.

Where painting is necessary, such as when customers order an optional two-part polyurethane exterior paint color, the completed hull is moved to a new climate and dust-controlled painting shop. Careful control of temperature, humidity, and dust are critical to a quality paint finish.

At the end of the manufacturing process, moveable final touch up sheds cover the yachts while crews complete any final details and prepare them for shipment.

New Selene Trawlers

Make & Model		Length	Beam	Draft
Selene 38 Ocean Trawler		41’9″	14’6″	4’8″
Selene 42 Ocean Trawler		41’9″	14’6″	4’8″
Selene 45 Ocean Trawler		46’11″	15’6″	5′
Selene 47 Ocean Trawler		50’1″	15’8″	5’1″
Selene 49 Ocean Trawler		53’11″	15’6″	5′
Selene 54 Ocean Trawler		59’10″	16’8″	5’9″
Selene 58 Ocean Trawler		63’7″	17’2″	5’10″
Selene 60 Ocean Trawler		65’1″	17’10″	5’8″
Selene 62 Ocean Trawler		68’10″	18’8″	6’5″
Selene 66 Ocean Trawler		72’6″	18’8″	5’6″

Brokerage Selene Trawlers

Used Selene Yachts For Sale

Selene Ocean Trawlers – Articles & Reviews

Click Here to Access Selene Ocean Trawlers Articles & Reviews



Contact Selene Expert, Kevin Frawley, for a private showing or sea trial: 954.790.0372.



Structure

• Bi-axis uni-direction stitched roving mat
• Glass Mat
• Divinycell core sandwich structure for hull side shell above water line and superstructure
• Longitudinal stringers and transverse frames system
• 3 watertight bulkheads
• chain locker, fwd. E/R, after E/R )
• Hull and deck joint sealed by glue, bolted and laminated with mat and woven roving
• Recessed bow thruster tunnel
• Integral FRP stern thruster casing
• Integral full protected keel and rudder shoe
• Hand laid FRP single skin hull bottom
• Integral swin platform with extended hull underneath

Exterior

• Manship S/S #316 opening port lights
• Manship S/S #316 hatches for fwd. and after stateroom
• Aritex port and starboard sliding door
• Taco S/S #316 solid upper and lower dual fender rails
• S/S #316 hand rail for fore deck, aft. deck and flybridge decks
• S/S #316 telescope ladder
• Teat Burgee and flag staffs
• Aluminum alloy window frames w/ power coated
• S/S #316 bow and stern flag pole socket
• Teak cap rail for side and after. deck
• Freeing port for fore, side, aft. deck and flybridge decks
• Molded inlay pattern non-skid to fore, side, aft. deck and flybridge decks
• Transom gates with step plate
• Side deck side gate, P&S
• FRP steps from aft. deck to flybridge
• Perko exterior courtesy lights
• Scandvik transom shower
• FRP settee at the cockpit
• FRP hatch to lazarette w/ S/S #316 ladder
• International anti-fouling paint
• International Gelshield primer coating
• International boot top line

Flybridge

• Helm station in center w/ console box
• S/S #316 destroyer type steering wheel
• S/S #316 grab rail
• S/S #316 bracket for fender
• Forespar Aluminum alloy hinged mast and boom
• Todd helm seat
• Drink well w/ FRP lid
• Entertainment space on the flybridge deck
• AFI 12V DC outlet
• Hatch on flybridge
• Polar wash basin w/ Scandvik folded faucet
• Table and Settee w/ storage underneath
• Tinted plexiglass windscreen in S/S #316 bracket

Interior Foundational Materials

• Light teak or cherry veneer (straight grain or mountain grain)
• R & C door locks and handles for interior sliding doors
• Schwepper door locks and handles for bathroom
• Lamp positive latching for all locker doors and drawers
• Solid teak and holly sole w/ teak border
• Fiberglass “I” shaped floor beam
• Vinyl and EVA foam panels for ceiling lining
• Draperies for saloon and each stateroom
• Settee with fabrics
• Hanging lockers w/ automatic light
• Storage cabinets
• Epifanes one part varnish for interior

Salon

• L-shaped settee w/ 5″ cushion set
• Fold-up dining table
• TV cabinet w/ sliding doors
• Emergency hatch to engine room
• Sliding door for saloon entrance
• Cantalupi dome lights
• Cabin reading light
• Corian or Granite counter top
• Exposed roof beams w/ wood caps
• Teak overhead grab rail
• Bamboo blinds
• Self-lock window stopper

Galley

• Overhang cabinets with wine glass storage
• Corian or Granite counter top and back splash
• Force 10 3-burners propane stove and oven w/ alarm monitor panel set
• Jabsco 12V DC electric exhaust fan above stove
• Tundra DC/AC refrigerator
• Single lever swivel type faucet
• S/S double sinks
• Drawers and cabinets w/ shelves under counter
• Overhang cabinets with wine glass storage

Pilothouse

• Helm station w/ instrument panels
• Upper console pannel box above steering station
• Digital Amp gauge
• Digital Volt gauge
• Hynautic hydraulic engine control system
• Hi-seat w/ footrest
• Sliding door P&S
• Cantalupi dome lights
• Cantalupi step lights
• Teak stair from pilothouse to fwd. stateroom

Master

• Queen size berth w/ 5″ foam mattress
• Drawer bureaus and side cabinets
• Cedar-lined wardrobe w/ automatic light
• Teak or Cherry veneer counter top
• Cabin reading lights
• Cantalupi dome lights
• Manship escape hatch

Master head

• Head compartment at the port side
• Vanity unit
• Procelain wash basin w/ integral counter top
• Shower room w/ teak removable grating panel at the starboard side
• Single lever hot and cold water shower faucet
• Tecma 12V DC freshwater toilet
• Jabsco 12V DC dia. 3″ exhaust fan
• Cantalupi dome lights
• Hubbell waterproof AC outlet in head
• Mirror with teak frame
• Medicine cabinet
• S/S #316 tissue paper holder

Forward stateroom

Forward head

• Head / shower room located at port side
• Vanity unit
• Porcelain wash basin w/ integral counter top
• Single lever hot and cold water shower faucet
• Teak removable grating panel
• Tecma 12V DC freshwater toilet
• Jabsco 12V DC dia. 3″ exhaust fan
• Cantalupi dome lights
• Hubbell waterproof AC outlet in head
• Mirror with teak frame
• S/S #316 tissue paper holder

Propulsion

• Single Cummins QSB5.9 230HP@2600RPM
• Deluxe engine panel w/ complete instrumentation and alarms
• Complete engine instrumentation at control station with
• Hynautic hydraulic engine control system at each helm station
• Aqua #22 propeller shaft ( dia. 2-1/4″=57mm )
• PYI dripless shaft seal
• Faster NiAlBr 4 blade propeller
• Jabsco 12V DC dia. 4″ engine room blowers
• FRP drip pan under engine
• Hydraulift FRP wet box muffler
• Full protected FRP rudder w/ S/S #316 rudder shaft
• Engine overheat and low oil pressure alarm
• Fluorescent light for E/R
• Watertight door to engine room
• Soundown E/R sound insulation system including damping tile, 3″ sound insulation foam & Aluminum perforated plate

Steering

• Hynautic hydraulic steering system for pilothouse and flybridge
• Handcrafted teak wheel in pilot house and S/S #316 dia. 28″ wheel on flybridge
• Emergency tiller
• Full protected FRP rudder

AC Electrical System

• 120V AC or 240V AC system
• Marinco 120V/240V 60hz 30Amp shore power inlets
• Marinco TV and Tel inlet
• Hubbell AC outlets throughout the boat, and GFCI in head and flybridge
• Newmar 3-bank 120V / 240V AC battery charger system
• Newmar 30 amp galvanic isolator
• Tundra upright DC/AC refrigerator
• Raritan 12 gallons 120V or 240V AC dual heating source hot water heater
• AC/DC control panel w/ polarity indicator lights, appropriate switches, meters and breakers
• Copper bonding strap w/ ground cable attachment for each fitting
• Two Zinc plates at transom for grounding system

DC Electrical System

• 12V DC system
• Muir HR1200 windlass w/ control switches at foredeck and each helm stations
• Sidepower 8hp electric bow thruster
• AFI 12V DC air horn
• Aqua Signal navigation lights
• Exalto 12V DC electric wipers for 3 front windshields w/ fresh water wash
• Rule 12V DC sump pumps w/ automatic float switches
• Rule sump pumps w/ automatic float switches
• Jabsco 12V DC dia. 3″ electric exhaust fan above stove
• Cantalupi accommodation dome lights
• Cantalupi step lights for interior and exterior
• Floject 12V DC electric pressurized fresh water pump
• Perko step lights for exterior
• Stereo speakers in saloon
• Vision AGM deep cycle batteries for house service, engine and generator starting
• Vimar Switch

Fuel System

• Total capacity 600 US gallons, two FRP fuel tanks w/ internal baffles, sumps, balancing lines, inspection ports and plates
• Racor 75/900 Max dual fuel filter / water separator for engine
• Ball valve for fuel system
• Electric fuel gauge
• Magnetic fuel sight gauge for each fuel tank
• Fuel management system

Plumbing System

• One FRP water tanks w/ shut off valve and sight gauge, total capacity 200 US gallons
• One FRP holding tank w/ Y-valve, Jabsco macerator pump, deck discharge outlet and remote full display panel in master head, total capacity 55 US gallons
• Electric water gauge
• Raritan 12 gallons 120V or 240V AC dual heating source hot water heater
• Plastic water piping system
• Sea cocks on all through hull fittings with double hose clamps
• Bronze basket type internal sea water strainer for main engine
• Rule electric bilge pumps w/ automatic float switch
• Whale manual bilge pump
• Shower sump pumps in both master and fwd. head
• Status panel w/ warning signal in helm station to warn of bilge pump operation

Anchor and Mooring System

• Muir 12V DC electric windlass
• Muir chain stopper
• S/S #316 self-launching anchor roller
• S/S #316 dia. 5″ diameter Samson post
• S/S #316 hawse hole with cleats
• FRP bow pulpit with chain wash dam
• Pilothouse and fore deck windlass control switch

Hydrostatic Data

• A/B Ratio(full load) – 2.12
• S/L Ratio(top speed) – 1.77
• S/L Ratio(cruising speed) – 1.45
• D/L Ratio(full load) – 362
• CB(block coefficient) – 0.33
• CP(prismatic coefficient) – 0.63



Contact Selene Expert, Kevin Frawley, for a private showing or sea trial: 954.790.0372.



Construction

• Cook gelcoat for hull, deck, superstructure & non-skid
• Vinylester resin for the first 5 layers lamination
• Cymax bi-axis uni-direction stitched roving / mat
• Taiwan Glass mat
• Divinycell core sandwich structure for hull side shell, deck & superstructure
• Longitudinal stringers & transverse frames system
• Collision locker
• 5 watertight bulkheads ( chain locker, Fwd. E/R, Aft. E/R, lazarette )
• Hull and deck joint sealed by glue, bolted & laminated with mat and woven roving
• Integral swim platform with extended hull underneath
• Recessed bow thruster tunnel
• Integral FRP stern thruster casing
• Integral full protected keel & rudder shoe
• Hand laid FRP single skin hull bottom

Exterior Hardware

• Manship S/S #316 opening portlights
• Manship S/S #316 hatches for pilothouse & fwd. stateroom
• Diamond/Sea-Glaze Dutch doors for pilothouse P&S & saloon
• Taco S/S #316 1-1/2″ solid upper & lower dual fender rails
• S/S #316 hand rail for fore deck & dinghy deck
• S/S #316 telescope swim ladder
• S/S #316 dia 2-1/2” aft. deck overhang support posts
• Aluminum alloy window frames w/ power coated
• Teak cap rail for side deck & aft. deck
• S/S #316 bow & stern flag pole socket
• Teak burgee & flag staffs
• Freeing port for fore, side & aft. decks
• Molded inlay pattern non-skid to fore, side, aft, F/B decks & swim platform
• Portuguese bridge access gate to fore deck
• Transom gates, swing out
• Storage lockers w/ teak grating inside Portuguese bridge
• S/S #316 self-lock type exterior gate handle
• Cantalupi exterior dome lights
• Cantalupi exterior courtesy lights

Flybridge

• Helm station in center w/ console box
• S/S #316 destroyer type steering wheel
• S/S #316 grab rail
• Watertight door from fly bridge to pilothouse
• FRP watertight sliding door ( S/S watertight sliding door optional )
• FRP BBQ box
• Polar wash basin w/ Scandvik folded faucet
• Forespar Aluminum alloy hinged mast & boom ( or FRP radar arch )
• AFI 24V DC outlet
• Todd helm seat ( the second helm seat is an option )
• Drink well w/ FRP lid
• Chart counter top
• Tinted plexiglass windscreen with S/S #316 bracket
• Dinghy space on the fly bridge deck
• Optional hydraulic davit available for lift
• Table & settee with storage underneath

Cockpit

• Dedicated spiral stair to F/B, with S/S #316 hand rail
• Scandvik transom shower
• Option FRP bureau ( can be acted as the 3rd station )
• FRP hatch to lazarette w/ S/S #316 ladder

Main Salon

• L-shaped sofa w/ 5″ foam cushion
• Storage underneath the sofa
• Hi-lo fold-up dining table
• Entertainment center w/ TV cabinet
• Emergency hatch to engine room
• Cantalupi dome lights
• Cabin reading light
• Diamond/Sea-Glaze Dutch door for saloon entrance
• Exposed roof beams w/ wood caps
• Teak overhead grab rail
• Bamboo blinds w/ drapes
• Tempered tinted glass for side windows
• Self-lock window stopper

Galley

• Counter top w/ Integral bar
• Corian or Granite counter top & back splash
• Seafeeze JT28 DC/AC refrigerator
• Jabsco 24V DC dia. 3″ electric exhaust fan above stove
• Force 10 3-burner propane stove w/ oven & alarm monitor panel set
• GE microwave w/ built-in exhaust as an option
• Single lever swivel type faucet
• Franke S/S #316 double sink
• Overhead cabinets
• Drawers & storage lockers under counter
• Trash bin w/ lid

Pilothouse

• Helm station w/ instrument panels
• Electronic engine control system
• Hi-seat w/ footrest & table – providing a near panoramic view
• Diamond/Sea-Glaze Dutch doors for pilothouse ( P&S )
• Sliding chart table w/ drawer
• Sliding watch berth behind hi-seat
• Dedicated teak stair from pilothouse to F/B
• Cantalupi dome lights
• Cantalupi step lights
• Daniel Smith chart light ( 1 )
• Cabin reading lights
• Teak overhead grab rails
• Tempered clear glass for front windshield

Master Stateroom

• Queen-size berth w/ 6″ foam mattress
• Side cabinets & drawer bureaus
• Wardrobe w/ automatic light & aromatic cedar liner
• TV cabinet w/ sliding door
• Teak or Cherry veneer counter top
• Cantalupi reading lights
• Cantalupi dome lights
• Mirror w/ teak frame
• Manship S/S #316 opening port lights

Master Head

• Tecma 24V DC freshwater toilet
• Jabsco 24V DC dia. 3″ exhaust fan
• Cantalupi dome lights
• Formica finish head lining & FRP bulkhead
• Corian or Granite counter top & back splash
• Vanity unit w/ integrated wash basin
• Tempered clear glass sliding shower door
• Mirror w/ wood frame
• Single lever hot & cold water shower faucet
• Medicine cabinet
• Shower room w/ teak removable grating panel
• Granite floor w/ stainless steel divider

Forward Stateroom

• Queen-size berth w/ 5″ foam mattress
• Front & side cabinets
• Hanging lockers w/ automatic light
• Teak or Cherry veneer counter tops
• Cabin reading lights
• Windline telescope escape ladder
• Manship S/S #316 escape hatch
• Manship S/S #316 opening port lights

Guest Stateroom

• Hi-lo berth
• 4″ foam mattress for each berth
• Hanging lockers w/ automatic light
• Overhead cabinet
• Book shelves
• Cabin reading lights
• Cantalupi dome lights

Engine & equipment Room

• Single John Deere 6125AFM 455HP@2000RPM
• Hynautic hydraulic engine control system at each helm station
• Deluxe engine panel w/ complete instrumentation & alarms
• Engine overheat & low oil pressure alarm
• Aqlla #22 propeller shaft ( dia. 3″=76.2mm )
• PYI dripless shaft seal
• Faster NiAlBr 4 blade propeller
• Jabsco 24V DC dia. 4″ engine room blowers
• FRP drip pan under engine
• FRP wet box muffler
• Full protected FRP rudder w/ S/S #316 rudder shaft
• S/S #316 pillars in engine room
• Fluorescent light for E/R, commissary & lazarette
• Watertight door from master stateroom to engine room

Steering System

• Hynautic hydraulic steering system for pilothouse & F/B
• Handcrafted teak wheel in pilothouse and S/S #316 dia. 30″ wheel on F/B
• Emergency tiller
• Full protected FRP rudder

AC Electrical System

• 120V AC or 240V AC system
• Northern Lights 12Kw. generator w/ sound shield, muffler and remote start switch panel located in P/H, including dedicated 120 Amp/hr starting battery in FRP box with lid
• 80 Amp engine alternator
• Heart Pathmaker emergency parallel switch
• Newmar 3-bank 120V / 240V AC battery charger system
• Newmar Integrated galvanic isolator
• Combomatic washer / dryer w/ louverd door
• Grunert 120V/230V AC holding plate freezer
• Torrid 20 gallons 120V/240V AC dual heating source hot water heater
• Grunert 120V/230V AC holding plate freezer
• Marinco 120V/240V 60hz 50Amp shore power inlets
• Marinco TV & Tel inlet
• Hubbell AC outlets throughout the boat, and GFCI in head & flybridge
• AC/DC control panel w/ polarity indicator lights, appropriate switches, meters & breakers Copper bonding strap w/ ground cable attachment for each fitting

DC Electrical System

• 24V DC system
• Maxwell electric windlass w/ up/down switches at foredeck & each helm stations
• Aqua Signal navigation lights
• Kahlenberg air horn
• Exalto 24V DC electric wipers for 3 front windshields including fresh water wash
• Groco 24V DC automatic water pressure pump with accumulator tank
• Rule sump pumps w/ Ultra float switches
• Vision AGM deep cycle batteries for house service, engine & generator starting
• Cantalupi accommodation dome lights
• Cantalupi step lights for interior & exterior
• Cabin reading lights
• Stereo speakers in stateroom

Fuel System

• Total capacity 1,500 US gallons, two FRP fuel tanks w/ internal baffles, sumps, balancing lines, inspection ports & plates
• Racor 75/1000 Max dual fuel filter / water separator for main engine
• Racor 900MA fuel filter / water separator for generator
• ESI fuel polishing system ( optional item )
• Racor USCG & CE certified fuel line hose
• Parker ball valve for fuel system
• Electric fuel gauge
• Magnetic fuel sight gauge for each fuel tank
• Fuel management system

Plumbing System

• Two FRP water tanks w/ shut off valve, total capacity 450 US gallons
• One FRP holding tank w/ Y-valve & Jabsco macerator pump, deck discharge outlet & remote full display panel in master head, total capacity 120 US gallons
• Electric water gauge
• Plastic water piping system
• Sea cocks on all through hull fittings with double hose clamps
• Bronze basket type internal sea water strainer for main engine
• Rule electric bilge pumps w/ Ultra float pump switch
• Whale manual bilge pump
• Shower sump pumps in both master & guest head
• Status panel w/ warning signal in helm station to warn of bilge pump operation

Anchor & Mooring

• FRP bow pulpit with chain wash dam
• Maxwell 24V DC horizontal electric windlass
• Maxwell chain stopper
• Maxwell chain meter ( optional item )
• S/S #316 self-launching anchor roller
• S/S #316 dia. 5″ diameter Samson post
• S/S #316 hawse hole with cleat ( 8 units )
• Fresh water chain wash down
• Salt water chain wash down

Hydrostatic Data

• A/B Ratio ( full load ) 2.34
• S/L Ratio ( top speed ) 1.63
• S/L Ratio ( cruising speed ) 1.43
• D/L Ratio ( full load ) 287
• CB ( block coefficient ) 0.38
• CP ( prismatic coefficient ) 0.73



Contact Selene Expert, Kevin Frawley, for a private showing or sea trial: 954.790.0372.



Construction

• Cook gelcoat for hull, deck, superstructure & non-skid
• Vinylester resin for the first 4 layers lamination
• Cymax bi-axis uni-direction stitched roving / mat
• Taiwan Glass mat
• Divinycell core sandwich structure for hull side shell above water line & superstructure
• Longitudinal stringers & transverse frames system
• 4 watertight bulkheads ( chain locker, fwd. E/R, after E/R, lazarette )
• Hull and deck joint sealed by glue, bolted & laminated with mat and woven roving
• Fixed swim platform
• Recessed bow thruster tunnel
• Integral FRP stern thruster casing
• Integral full protected keel & rudder shoe
• Hand laid FRP single skin hull bottom

Exterior Hardware

• Manship S/S #316 opening portlights
• Manship S/S #316 hatches for pilothouse & fwd. stateroom
• Diamond/Sea-Glaze Dutch doors for pilothouse P&S, saloon entrance
• Taco S/S #316 solid upper & lower dual fender rails
• S/S #316 hand rail for fore deck & dinghy deck
• S/S #316 telescope swim ladder
• S/S #316 dia 2-1/2″ aft. deck overhang support posts
• Aluminum alloy window frames w/ power coated
• Teak cap rail for side & after deck
• S/S #316 bow & stern flag pole socket
• Teak cap rail for side & after deck
• Teak burgee & flag staffs
• Freeing port for fore, side & aft. deck
• Molded inlay pattern non-skid to fore, main & fly bridge decks
• Transom gates, swing out, P&S
• After deck side gate, swing out
• Portuguese bridge gate, swing out
• Storage lockers w/ teak removable grating panel inside Portuguese bridge
• S/S #316 self-lock type exterior gate handle
• FRP bench seat at Portuguese bridge (option)
• Cantalupi exterior dome lights
• Cantalupi exterior courtesy lights

Flybridge

• Helm station in center w/ console box
• S/S #316 destroyer type steering wheel
• S/S #316 grab rail
• Sliding watertight door from fly bridge to pilothouse
• Forespar Aluminum alloy hinged mast & boom
• Todd helm seat ( the second helm seat is an option )
• Drink well w/ FRP lid
• Chart counter top
• Tinted plexiglass windscreen with S/S #316 bracket
• Entertainment space on F/B deck

Cockpit

• Scandvik transom shower
• FRP bureau ( optional item )
• FRP hatch to lazarette w/ S/S #316 ladder

Main Salon

• L-shaped sofa w/ 5″ foam cushion
• Storage underneath the sofa
• Hi-lo fold-up dining table
• TV cabinet w/ sliding doors
• Entertainment center w/ TV cabinet
• Emergency hatch to engine room
• Cantalupi dome lights
• Cabin reading lights
• Corian or Granite counter top
• Diamond/Sea-Glaze Dutch door for salon entrance
• Exposed roof beams w/ wood caps
• Teak overhead grab rail
• Bamboo blinds
• Self-lock window stopper

Galley

• Counter top w/ Integral bar
• Overhang cabinets with wine glass storage
• Corian or Granite counter top & back splash
• Tundra T-80 DC/AC refrigerator
• Jabsco 12V DC dia. 3″ electric exhaust fan above stove
• GE microwave w/ built-in exhaust as an option
• Single lever swivel type faucet
• Frankie S/S #316 double sink
• Drawers & storage lockers under counter
• Trash bin
• Force 10 3-burner propane stove w/ alarm monitor panel set

Pilothouse

• Helm station w/ instrument panels
• Upper console box above steering station
• Digital Amp gauge
• Digital Volt gauge
• Morse mechanical engine control system
• Hi-seat w/ footrest & table
• Diamond/Sea-Glaze Dutch doors for pilothouse P&S
• Sliding chart table w/ drawer
• Sliding watch berth behind hi-seat
• Dedicated teak stair from pilothouse to F/B
• Cantalupi dome lights
• Cantalupi step lights
• Daniel Smith chart lights ( 1 )
• Cabin reading lights
• Teak overhead grab rails

Master Stateroom

• Queen-size berth w/ 5″ foam mattress
• Side cabinets & drawer bureaus
• Side & front cabinets
• Drawer bureaus
• Wardrobe w/ automatic light & aromatic cedar liner
• TV cabinet w/ sliding door
• Teak or Cherry veneer counter top
• Cantalupi reading lights
• Cantalupi dome lights
• Manship escape hatch
• Manship S/S #316 opening portlights
• Book shelves
• Windline telescope escape ladder

Master Head

• Tecma 12V DC freshwater toilet
• Jabsco 12V DC dia. 3″ exhaust fan
• Cantalupi dome lights
• Formica finish ceiling lining & FRP bulkhead
• Corian or Granite counter top & back splash
• Vanity unit w/ integrated wash basin
• Mirror w/ teak frame
• Itai Aluminum sliding shower door
• Manship S/S #316 opening portlights
• Single lever hot & cold water shower faucet
• Medicine cabinet
• Shower room w/ teak removable grating panel
• Granite floor w/ stainless steel divider

Forward Stateroom

• Hi-lo berth
• 4″ foam mattress for each berth
• Hanging lockers w/ automatic light
• Overhead cabinet
• Cabin reading lights
• Cantalupi dome lights
• Side counter top with storage locker underneath

Guest Head

• Tecma 12V DC freshwater toilet
• Jabsco 12V DC dia. 3″ exhaust fan
• Cantalupi dome lights
• Formica finish ceiling lining & FRP bulkhead
• Granite or Corian counter top & back splash
• Manship S/S #316 opening portlights
• Itai sliding shower door
• Vanity unit w/ integral wash basin
• Single lever hot & cold shower faucet
• Granite floor w/ stainless steel divider ( or teak & holly floor w/ teak border )
• Mirror w/ teak frame

Commissary

• Access hatch to commissary w/ teak step
• Wine cellar
• Cabinets & storage
• Rubber non-skid floor
• Ceiling lights
• Choice of being deleted to enlarge the engine room

Engine Room

• Single Cummins QSB5.9 230HP@2600RPM
• Deluxe engine panel w/ complete instrumentation & alarms
• Engine overheat & low oil pressure alarm
• Morse mechanical engine control system at each helm station
• Aqua #22 propeller shaft ( dia. 2-1/2″=63.5mm )
• PYI dripless shaft seal
• Faster NiAlBr 4 blade propeller
• Jabsco 12V DC dia. 4″ engine room blowers
• FRP drip pan under engine
• Hydraulift FRP wet box muffler
• Full protected FRP rudder w/ S/S #316 rudder shaft
• S/S #316 pillars in engine room
• Fluorescent light for E/R, commissary & lazarette
• Watertight door to engine room
• Soundown E/R sound insulation system including damping tile, 3″ sound insulation foam & Aluminum perforated plate
• Engine room FRP flooring

Steering System

• Hynautic hydraulic steering system for pilothouse & F/B
• Handcrafted teak wheel in pilot house and S/S #316 dia. 28” wheel on F/B
• Emergency tiller
• Full protected FRP rudder

AC Electrical System

• 120V AC or 240V AC system
• Northern Lights 8Kw. generator w/ sound shield, muffler and remote start switch panel located in P/H, includes dedicated 120 Amp / hr starting battery in FRP box with lid
• Delco 105 Amp engine alternator
• Heart Pathmaker emergency parallel switch
• Newmar 3-bank 120V / 240V AC battery charger system
• Tundra upright DC / AC refrigerator
• Combomatic washer / dryer w/ louverd door
• Grunert 120V/230V AC holding plate freezer
• Torrid 20 gallons 120V/240V AC dual heating source hot water heater
• Marinco 120V/240V 60hz 50Amp shore power inlets
• Marinco TV & Tel inlet
• Hubbell AC outlets throughout the boat, and GFCI in head & flybridge
• AC/DC control panel w/ polarity indicator lights, appropriate switches, meters & breakers
• Copper bonding strap w/ ground cable attachment for each fitting

DC Electrical System

• 12V DC system
• Muir HR2500 windlass w/ control switches at foredeck & each helm stations
• Aqua Signal navigation lights
• AFI 12V DC air horn
• Roca 12V DC electric wipers for 3 front windshields w/ fresh water wash
• Rule 12V DC sump pumps w/ automatic float switches
• Rule sump pumps w/ automatic float switches
• Jabsco 12V DC dia. 3″ electric exhaust fan above stove
• Cantalupi accommodation dome lights
• Cantalupi step lights for interior & exterior
• Floject 12V DC electric pressurized fresh water pump
• Floject 12V DC deck wash pump
• Stereo speakers in saloon w/ wiring to cabinet
• Vision AGM deep cycle batteries for house service, engine & generator starting

Fuel System

• Total capacity 800 US gallons, two FRP fuel tanks w/ internal baffles, sumps, balancing lines, inspection ports & plates
• Racor 75/900 Max dual fuel filter / water separator for main engine
• Racor 900MA fuel filter / water separator for generator
• ESI fuel polishing system
• Racor USCG & CE certified fuel line hose
• Parker ball valve for fuel system
• Electric fuel gauge
• Magnetic fuel sight gauge for each fuel tank
• Fuel management system

Plumbing System

• One FRP water tanks w/ shut off valve & sight gauge, total capacity 200 US gallons
• One FRP holding tank w/ Y-valve, Jabsco macerator pump, deck discharge outlet & remote full display panel in master head, total capacity 60 US gallons
• Electric water gauge
• Plastic water piping system
• Sea cocks on all through hull fittings with double hose clamps
• Bronze basket type internal sea water strainer for main engine
• Rule electric bilge pumps w/ automatic float switch
• Whale manual bilge pump
• Shower sump pumps in both master & guest head
• Status panel w/ warning signal in helm station to warn of bilge pump operation

Anchor & Mooring System

• uir 12V DC electric windlass
• Muir chain stopper
• Chain meter (option)
• S/S #316 self-launching anchor roller
• S/S #316 dia. 5″ Samson post
• S/S #316 hawse hole with cleats
• Seawater chain wash down

Hydrostatic Data

• /B Ratio ( full load ) 2.60
• S/L Ratio (top speed) 1.65
• S/L Ratio (cruising speed) 1.42
• D/L Ratio (full load) 381
• CB (block coefficient) 0.33
• CP (prismatic coefficient) 0.67
• GM (full-load) 4′-1″



Contact Selene Expert, Kevin Frawley, for a private showing or sea trial: 954.790.0372.



Construction

• Cook gelcoat for hull, deck, superstructure & non-skid
• Vinylester resin for the first 5 layers lamination
• Cymax bi-axis uni-direction stitched roving / mat
• Taiwan Glass mat
• Divinycell core sandwich structure for hull side shell, bottom, deck & superstructure
• Longitudinal stringers & transverse frames system
• 5 watertight bulkheads ( chain locker, Fwd. E/R, Aft. E/R, lazarette )
• Collision locker
• Hull and deck joint sealed by glue, bolted & laminated with mat and woven roving
• Integral swim platform with extended hull underneath
• Recessed bow thruster tunnel
• Integral FRP stern thruster casing
• Integral full protected keel & rudder shoe

Exterior Hardware

• Manship S/S #316 opening portlights
• Manship S/S #316 hatches for pilothouse & fwd. stateroom
• Oceanair hatch shade w/ insert screens
• Diamond/Sea-Glaze Dutch doors for pilothouse P&S, salon & E/R entrance
• Taco S/S #316 1-1/2″ solid upper & lower dual fender rails
• S/S #316 oval shaped hand rail for fore deck & dinghy deck
• S/S #316 telescope swim ladder
• Aluminum alloy window frames w/ power coated
• Teak cap rail for Portuguese bridge, side deck & aft. deck
• S/S #316 bow & stern flag pole socket
• Teak burgee & flag staffs
• Freeing port for fore, side & aft. deck
• Molded inlay pattern non-skid to fore, side, aft, F/B decks & swim platform
• Portuguese bridge access gate to fore deck
• After deck side gates, swing in
• Transom gates, swing out
• Portuguese side gates, swing out, P&S
• Storage lockers w/ teak grating inside Portuguese bridge
• S/S #316 self-lock type exterior gate handle
• Cantalupi exterior dome lights
• Cantalupi exterior courtesy lights

Flybridge

• Helm station in center w/ console box
• S/S #316 dia. 32″ destroyer type steering wheel
• S/S #316 grab rail
• S/S #316 sliding door from F/B to pilothouse
• FRP BBQ box
• Polar wash basin
• Todd helm seat ( 2 )
• AFI 24V DC outlet
• Chart counter top
• Tinted plexiglass windscreen with S/S #316 bracket
• Dinghy space on the fly bridge deck
• FRP U-shaped settee w/ storage underneath

Cockpit

• FRP settee w/ Sunbrella cushion
• Teak table w/ S/S #316 table pedestal
• Fresh water deck wash
• Flojet saltwater wash down pump
• Dedicated spiral stair to F/B
• Steps to swim platform
• Foldable cleats at swim platform (Option)
• Scandvik transom shower
• FRP bureau (can be acted as the 3rd station) (Option)

Main Salon

• U-shaped sofa w/ 5″ foam cushion
• Storage underneath the sofa
• Table & corner tables
• Entertainment center w/ TV / video cabinet
• Cantalupi wall light
• Cabin reading light
• Diamond/Sea-Glaze Dutch door for salon entrance
• Emergency hatch to engine room
• Corian or Granite bar counter top
• Teak or cherry swivel chairs w/ 2″ foam cushion
• Bamboo blinds w/ drapes
• Self-lock window stopper

Galley

• Counter top w/ Integral bar
• Corian or Granite counter top & back splash
• Sea Freeze JT26 refrigerator
• Jabsco 24V DC dia. 3” electric exhaust fan above stove
• Force 10 3-burner propane stove w/ oven & alarm monitor panel set
• GE microwave w/ built-in exhaust
• Single lever swivel type faucet
• Franke S/S #316 double sink
• Overhead cabinets
• Drawers & storage lockers w/ shelves under counter
• Trash bin w/ lid

Pilothouse

• Helm station w/ instrument panels
• Upper console box above steering station
• Electric engine control
• Diamond/Sea-Glaze Dutch doors for P&S side
• Sliding watch berth behind raised seat
• Chart table w/ drawer
• S/S #316 or teak stair from pilot house to F/B
• Raised seat w/ foot rest
• Manship S/S #316 hatch
• Oceanair hatch shade w/ insect screen
• Teak overhead grab rail
• Cantalupi red lights ( 2 )
• Cantalupi step lights
• Cantalupi dome lights
• Daniel Smith chart lights
• Cabin reading lights

Master Stateroom

• Queen-size berth w/ 6″ foam mattress
• Side cabinets & drawer bureaus
• Safe located at master stateroom or office
• Wardrobe w/ automatic light & aromatic cedar liner
• TV / video cabinet
• Teak, Cherry or Granite veneer counter top
• Cantalupi reading lights
• Cantalupi dome lights
• Manship S/S #316 opening portlights
• Windline telescope escape ladder
• Dedicated teak stairway to main salon

Master Head

• Tecma 24V DC freshwater toilet
• Jabsco 24V DC dia. 3″ exhaust fan
• Cantalupi dome lights
• Formica finish head lining & FRP bulkhead
• Corian or Granite counter top & back splash
• Vanity unit w/ integrated wash basin
• Tempered clear glass sliding shower door
• Manship S/S #316 opening portlights
• Single lever hot / cold water shower faucet
• Medicine cabinet w/ mirror door
• Vanity mirror w/ teak frame
• Granite floor w/ stainless steel divider (or teak & holly floor with teak boarder)
• Teak removable grating for shower room

VIP Stateroom

• Queen-size berth w/ 5″ foam mattress
• Side cabinets & drawer bureaus
• Wardrobe w/ automatic light & aromatic cedar for the liner
• TV cabinet
• Teak or Cherry veneer counter top
• Cabin reading lights
• Cantalupi dome lights
• Windline telescope escape ladder
• Manship S/S #316 hatch
• Manship S/S #316 opening portlights with storm cover

VIP Head

• Tecma 24V DC freshwater toilet
• Jabsco 24V DC dia. 3″ exhaust fan
• Formica finish ceiling lining & FRP bulkhead
• Corian or Granite counter top & back splash
• Cantalupi dome lights
• Tempered clear glass sliding shower door
• Manship S/S #316 opening portlights
• Teak removable grating panel for shower room
• Vanity unit w/ mirror
• Itai Aluminum sliding shower door
• Teak removable grating panel for shower room
• Single lever hot / cold water shower faucet
• Medicine cabinet w/ mirror door
• Granite floor w/ stainless steel divider (or teak & holly floor w/ teak border)

Guest Stateroom

• Teak battens on side ceiling
• Twin berth w/ drawer underneath
• Book shelves
• 5″ foam mattress for each berth
• Hanging locker w/ automatic light
• Overhead cabinet at port side
• Cabin reading lights
• Vanity bureau
• Vanity mirror w/ teak frame
• Manship S/S #316 opening port lights

Guest Head

• Tecma 24V DC freshwater toilet
• Jabsco 24V DC 3″ exhaust fan
• Formica finish ceiling lining & FRP bulkhead
• Corian or Granite counter top & back splash
• Cantalupi dome lights
• Tempered clear glass sliding shower door
• Manship S/S #316 opening portlights
• Teak removable grating for shower room
• Vanity unit w/ integral wash basin
• Medicine cabinet w/ mirror door
• Single lever hot / cold water shower faucet
• Granite floor w/ stainless steel divider (or teak & holly floor w/ teak border)

Crew Quarters

• Dedicated access from side deck to crew quarters
• Bunk w/ 4″ foam mattress & drawer underneath
• Hanging locker w/ automatic light & aromatic cedar liner
• Cantalupi dome lights
• Cabin reading lights
• Book shelf
• Overhead locker
• Laundry lockers w/ louvered door

Crew Head

• Tecma 24V DC freshwater toilet
• Jabsco 24V DC dia. 3″ exhaust fan
• Formica finished ceiling lining & FRP bulkhead
• Corian or Granite counter top & back splash
• Cantalupi dome lights
• Vanity unit w/ integral wash basin
• Single lever hot / cold water shower faucet
• Teak removable grating panel for shower room

Engine Room

• Electric engine control system at each helm station
• Deluxe engine panel w/ complete instrumentation & alarms
• Engine overheat & low oil pressure alarm
• Aqua #22 propeller shaft ( dia. 3″=76.2mm )
• PYI dripless shaft seal
• Faster NiAlBr 4 blade propeller
• Reverso gear driven oil change pump
• FRP drip pan under engine
• Hydraulift FRP wet box muffler
• Engine room blowers dia. 5″ 120/230V AC ( 4 units )
• Full protected FRP rudder w/ S/S #316 dia. 2-1/2″ shaft
• S/S #316 pillars in engine room
• Fluorescent light for E/R, commissary & lazarette
• Watertight door to engine room

Fuel & Plumbing Systems

• Fuel System:
• Two FPR fuel tanks w/ internal baffles, sumps, balancing lines, inspection plates, total capacity 2,200 US gallons
• Racor 75/1000 Max dual fuel filter / water separator for main engine
• Racor 900MA fuel filter / water separator for generator
• ESI fuel polishing system
• Racor USCG & CE certified fuel line hose
• Parker ball valve for fuel system
• Electric fuel gauge
• Magnetic fuel sight gauge for each fuel tank
• Fuel management system
• Plumbing System:
• Plastic water piping system
• Electric water gauge
• Two FRP water tanks w/ shut off valve, total capacity 600 gallons
• One FRP 250 gallons holding tank w/ Y-valve & Jabsco macerator pump, deck discharge outlet & remote full display pane
• Sea cocks on all through hull fittings with double hose clamps
• Bronze basket type internal sea water strainer for main engine
• Rule electric bilge pumps w/ automatic float switch
• Whale manual bilge pump
• Status panel w/ warning signal in helm station to warn of bilge pump operation

Steering

• Hynautic hydraulic steering system for two stations
• Handcrafted teak wheel in pilot house and S/S #316 wheel on F/B
• Emergency tiller
• Full protected FRP rudder

Electrical System

• AC Electrical:
• 120V AC or 240V AC system
• One Northern Lights 20Kw. generator w/ sound shield, muffler and remote start switch panel located in P/H, includes dedicated 120 Amp / hr starting battery
• 80 Amp engine alternator
• Heart Pathmaker emergency parallel switch
• Marinco shore power inlets
• Marinco TV & Tel inlet
• Hubbell AC outlets throughout the boat
• Newmar integrated galvanic isolator
• Asko separated washer / dryer
• Torrid S/S 30 gallons 120V/ 240V AC dual heating source water heater
• AC/DC control panel w/ polarity indicator light, appropriate switches, meters & breakers
• Hubbell GFCI outlet in head & flybridge
• Copper bonding strap w/ ground cable attachment for each fitting
• 3-bank 120V/240V AC battery charger system
• Mastervolt or equivalent 3-bank 120V or 240V AC battery charger unit
• Spare circuit breaker for optional Auto pilot system
• DC Electrical:
• 24V DC system
• Maxwell HWVC 3500 windlass w/ up/down switches at foredeck & each helm stations
• Aqua Signal navigation lights
• Kahlenberg air horn
• Exalto electric wipers for 3 front windshields w/ fresh water wiper wash
• Groco automatic water pressure system
• Rule sump pumps w/ ultra float switches
• Vision AGM deep cycle batteries for house service, engine & generator starting
• Cantalupi accommodation dome lights
• Cantalupi step lights for interior & exterior
• Stereo speakers in stateroom

Hydrostatic Data

• A/B Ratio (full load) 2.46
• S/L Ratio (top speed) 1.57
• S/L Ratio (cruising speed) 1.31
• D/L Ratio (full load) 330
• CB (block coefficient) 0.32
• CP (prismatic coefficient) 0.66



Contact Selene Expert, Kevin Frawley, for a private showing or sea trial: 954.790.0372.



Construction

• Bi-axis uni-direction stitched roving mat
• Glass Mat
• Divinycell core sandwich structure for hull side shell above water line and superstructure
• Longitudinal stringers and transverse frames system
• 3 watertight bulkheads
• chain locker, fwd. E/R, after E/R )
• Hull and deck joint sealed by glue, bolted and laminated with mat and woven roving
• Recessed bow thruster tunnel
• Integral FRP stern thruster casing
• Integral full protected keel and rudder shoe
• Hand laid FRP single skin hull bottom
• Integral swim platform with extended hull underneath

Exterior Hardware

• Manship S/S #316 opening portlights
• Manship S/S #316 hatches for fwd. and after stateroom
• Aritex port and starboard sliding door
• Taco S/S #316 solid upper and lower dual fender rails
• S/S #316 hand rail for fore deck, aft. deck and flybridge decks
• S/S #316 telescope ladder
• Teat Burgee and flag staffs
• Aluminum alloy window frames w/ power coated
• S/S #316 bow and stern flag pole socket
• Teak cap rail for side and after. deck
• Freeing port for fore, side, aft. deck and flybridge decks
• Molded inlay pattern non-skid to fore, side, aft. deck and flybridge decks
• Transom gates with step plate
• Side deck side gate, P&S
• FRP steps from aft. deck to flybridge
• Perko exterior courtesy lights
• Scandvik transom shower
• FRP settee at the cockpit
• FRP hatch to lazarette w/ S/S #316 ladder
• International anti-fouling paint
• International Gelshield primer coating
• International boot top line



Contact Selene Expert, Kevin Frawley, for a private showing or sea trial: 954.790.0372.
