36' Farr 2007 Cassiopeia

Los Angeles, CA, US

Previously Asking $137,777

Off Market

Description

Contact Dave Millett at Denison Yacht Sales 714-260-5901

OR

Harmen Rockler at Farr Yacht Design 410-267-0780

Free Shipping anywhere in the Continental US

Trades Considered

Reimbursement of two plane tickets to sea trial and survey if purchase completed



The Farr 11s represents the culmination of intense discussions with a previous client.  The carefully prepared brief called for an inshore boat with sufficient freeboard for coastal race capability, legs out hiking and minimal interior. The goal was to produce a very fast boat keelboat for its size (35 to 38 ft) crewed by no more than 6. Racing venues included Key West, the Great Lakes and a variety of other regattas.

There has been considerable interest world wide in a mono hull that fits this vision and there are a number of examples similar to this style of boat. The acceptance of canting keel technology and the incredible outright speed of the VO 65's and Open 60's has opened many sailors' minds to new frontiers of high performance monohull sailing.

The obvious goals are to provide high stability to carry a powerful sail plan, keep the whole package as light as possible, reduce drag, and produce a boat that will break out into high speeds in a controllable manner. These goals are blended with the desire to be a good all rounder for buoys races in a wide range of wind speeds, good in coastal type races where reaching performance and handling are important, and avoid any glaring weaknesses that are seen in some attempts at this concept.

The Farr 11s has a 45-degree canting keel, twin asymmetric canards and twin retractable rudders on a hull with high form stability. The hull shape combines the demands for minimizing light air (low speed) drag with high-speed stability and excellent handling qualities. Twin rudders will help control in extreme conditions.

The rig is a transplant from skiff rig development with a large square-headed main on a highly swept spreader, no backstay rig. The concept provides automatic de powering and minimizes demands on the crew during maneuvers to leave hands available for canard operation, keel activation and sail handling. The retractable bowsprit stretches the sail plan to allow ample downwind sail area in the form of asymmetric spinnakers.

Construction is in carbon skin honeycomb core sandwich, with carbon keel fin, and an all up weight of 2400 Kg. The keel is activated by a hydraulic ram/electric pump system.

How Fast Do You Want To Go Today!









Yacht Overview


  • Yacht Details 36' Farr 2007
  • Location Los Angeles, CA, US
  • Engines
  • Beam 11' 2''
  • Draft 8' 8''
  • Staterooms

Specifications

  • Beam: 11' 2''
  • Hull Material: Composite
  • Max Draft: 8' 8''
  • Displacement: 5,300 lb
  • Fuel Tank: 1 x |
  • Fresh Water: 1 x |
  • Holding: 1 x |
  • Heads: 1

Additional Information

Additional Information

Mechanical:

Mercury 15hp outboard motor mounted on transom

Qty 2- 6 gallon fuel tanks with lines

Electric and manual bilge pump systems (New 2016)



Electrical:

24V systems for keel and hydraulic pump

12V system for navigation and boat instruments

Battery isolation and circuit breaker panels

24V 3 bank battery charging system

All batteries new 2016



Interior:

Awlgrip finish in service areas (new 2016)

Qty 2 carbon pipe berths

Gimbaled jet boil stove

Carbon fiber sink

Cloth storage systems Port and Starboard

Soft shackle carbon pad eyes for hanging bags

Interior optimized for overnight point to point racing



Hardware:

Spinlock organizers and stoppers

Bow Pulpit, Stern pushpits, eight stations

Stainless steel life lines

Harken winches

                Qty2 B45.2STR Aluminum 2 speed self tailing

                Qty3 B45.2STRQ Aluminum self tailing Quattro

Harken blocks and sailing hardware

Harken athwart ship tracks



Rudder and Steering:

Carbon stock, foam core, carbon blade (faired and painted 2016)

Transom hung carbon rudder cassettes

Windward blade lifts to reduce wetted surface

Under deck steering linkage

Carbon fiber tiller



Keel:

Faired and painted 2016

CNC machined carbon keel fin

Machined lead bulb

+/- 45 degree canting each side

Removable for trailering



Keel System:

45 degree cant per side

10 seconds to full cant

Stainless hydraulic cylinder (rebuilt 2016)

Electric DC hydraulic power pack (inspected and serviced 2016)



Spars:

Formula Carbon mast and boom clear coated and serviced 2016

New Southern Spars rod rigging 2016

Carbon retractable sprit clear coated 2016

Complete racing running rigging in great shape

Carbon fiber instrument bracket

Carbon asymmetric canards clear coated 2016



Sails:

Elliott Pattison #1 Jib      used twice

Elliott Pattison A2 spinnaker used twice

Elliott Pattison A3 spinnaker never used

Quantum Carbon mainsail good condition

North A1 spinnaker good condition QTY 2

North A2 spinnaker good condition QTY 2

North Code Zero, used very little

North 155% Genoa on carbon furler

North Light jib QTY 2

North heavy jib QTY 2



Electronics:

B&G H3000 system with race processor, H2000 compass

Furuno GP 37 GPS

Garmin 19x GPS

ICOM M 421 VHF

Carbon computer mount and edgeport system for interface

2016 Update

2016 Update

Boat had a complete refit, with faired bottom and blades in 2016.  All systems were gone through extensively with everything serviced to excellent condition.  All spars and canards sanded and clear coated.  Interior of boat optimized for point to point distance racing with lightweight storage systems and nav station.
