52' Latini Marine 2006 Conviction

Dana Point, CA

$185,000

  • Length 52’
    Location Dana Point, CA
  • Beam 14'
  • Draft 11'
  • Staterooms
  • Engine(s) Yanmar
  • Price $185,000





Loading Broker Contact...


Description

  • 2006 ULDB Racing Design Transpac 52
  • Botin Design built by Lanti Marine Italy
  • Carbon Composite Build
  • After several years of success on both sides of the Atlantic, she was sold to an American owner by this firm in 2009 and new sails and a new keel and bulb were added in 2012.   She was then donated and sailed under the flag of Kings Point.  After her donation period was up, she was sold to her present owner, who has raced her from the Carribbean to the Med.  Having just arrived in California for the 50th Transpac Race to Hawaii





Engine(s)

  • Make Yanmar
  • Model 4JH4E
  • Fuel Diesel
  • Type Inboard
  • Drive Type Sail

Specifications

  • Cruising Speed: 10 kn
  • Maximum Speed: 25 kn
  • Beam: 14'
  • Hull Material: Composite
  • Max Draft: 11'
  • Fuel Tank: 1 x 21|gallon
  • Fresh Water: 5 x |
  • Single Berths: 8
  • Heads: 1
  • Dry Weight: 16,000 lb

Description




FROM SURVEY DONE JULY 5TH 2019 PACIFIC MARINE SURVEYORS



The vessel "Conviction", bearing Barbados Document No. 00268 (vessel was not built in USA),

was built by Latini Marine in Italy of carbon fiber in 2006. The vessel is a diesel-auxiliary, sailing

sloop known as a Transpac 52, or TP52.

The hull construction is from a female mold, hand laid up, using appropriate layers of carbon fiber

matte, cloth and woven roving with resin. There is a gel coat finish on the exterior portions of the

vessel. The deck and superstructure are of the same type of construction; however, some areas

are cored and there is a nonskid pattern on the walking surface. There are transverse carbon fiber

bulkheads, intermittent framing and longitudinal stringers along with a deck-to-hull joint that gives

the vessel its rigidity and stiffness.

Boarding the vessel onto the open, aft cockpit, there is an emergency life raft tied down on the

stern. Forward of that there are two (2) carbon fiber pedestals with wheels. Between the

pedestals is a "coffee grinder" and navigational equipment, and there is adequate sailing

paraphernalia in the adjacent areas.

There are decks on the port and starboard sides leading forward for sail handling and other uses.

The carbon fiber, keel-stepped mast is supported with stainless steel rod standing rigging. There

is yacht braid running rigging. There is a stainless steel bow pulpit with a carbon fiber bow sprit.

Entering the vessel from the forward section of the cockpit, down a set of stairs puts you in the

main living quarters. On the port and starboard sides are a total of eight (8) pipe berths (four on

either side) running aft. Beneath the companionway stairs and the cockpit, on centerline, is the

location of the auxiliary engine. The engine, a small nav station and the fuel tanks are located in

this area. Aft of that is the rudder post and steering quadrant. There is also extra storage aft.

Continuing forward of the pipe berths in the main cabin, on the port side is a small galley sink, and

to starboard is a small Jetboil stove. Continuing forward through the bulkhead, immediately to port

is a manual marine toilet. Forward of this area is a sail storage locker, with one (1) cabin top hatch

providing light and air to this cabin.

RIGGING

Keel-Stepped Carbon Fiber Mast w/ Two (2) Sets of Spreaders, Stainless Steel Rod Standing

Rigging, Yacht Braid Running Rigging, Windex, Internal Halyards, Running Backstay, Hydraulic

Headstay, Yacht Braid Boom Vang, Mainsheet Traveler, Turning Blocks, Line Stoppers, Six (6)

Harken Carbon Fiber Self-Tailing Winches, Two (2) Carbon Fiber "Coffee Grinders".

 DECK LEVEL INSPECTION:

The chain plates, turnbuckles, shrouds and halyards all appear to be serviceable.
