102' Cantiere Delle Marche 2015 ACALA

Golfito, Costa Rica

Previously Asking $7,995,000

Off Market

Description

'ACALA' is hull #1 in the popular CdM Darwin 102 Series having been custom build for an experienced yachtsman with an owner's project manager on site for the duration of the entire build overseeing all aspects of the construction. Since being sold to the second owner in late 2020 'ACALA' has completed her RINA 5 year class survey as well as full service of all major machinery with a significant financial investment into the vessel during a substantial 4 month yard period at Lauderdale Marine Center.

'ACALA' has traveled extensively since being delivered both in the Mediterranean, Caribbean, Mexico and the Pacific. Her shore power converters and substantial tender make her a true global cruiser with her full displacement, steel hull & 4,500nm range.

'ACALA' comfortably sleeps up to 12 guests in 5 cabins + crew accommodations for 7 including a captain's cabin on the upper deck which is rare for a 100ft yacht.

She has been professionally maintained since new with a full time crew & never chartered.

'ACALA' represents the best value for an explorer yacht on the market today.

Yacht Overview


  • Yacht Details 102' Cantiere Delle Marche 2015
  • Location Golfito, Costa Rica
  • Engines
  • Beam 24' 3''
  • Draft 8'
  • Staterooms 5



Loading Broker Contact...


Specifications

  • Cruising Speed: 10 kn
  • Maximum Speed: 13 kn
  • Beam: 24' 3''
  • Hull Material: Steel
  • Max Draft: 8'
  • Fuel Tank: 1 x 10600|gallon
  • Fresh Water: 1 x 1585|gallon
  • Holding: 1 x 550|gallon
  • Single Berths: 6
  • Double Berths: 3
  • Cabins: 5
  • Heads: 6

Overview And Walk-through


'ACALA' is Hull #1 of the popular CdM Darwin 102 Series having been custom built for an experienced yachtsman with an owner's project manager on sight for the duration of the entire build overseeing all aspects of the construction.Since being sold to the second owner in late 2020 'ACALA' has completed her RINA 5 year class survey as well as full service of all major machinery with a significant financial investment into the vessel during a substantial 4 month yard period at Lauderdale Marine Center.

'ACALA' has traveled extensively since being delivered both in the Mediterranean, Caribbean, Mexico and the Pacific. Her shore power converters and substantial tender make her a true global cruiser with her full displacement, steel hull & 4,500nm range.

'ACALA' comfortably sleeps up to 12 guests in en-suite 5 cabins + crew accommodations for 7 including a captain's cabin on the upper deck which is rare for a 100ft yacht. The guest cabins are all located on the lower deck with crew cabins forward of the galley on the main deck.

Both her main salon and sky lounge have floor to ceiling sliding glass doors that can be completely moved to the side thus combining interior & exterior spaces into one. Inviting furniture, custom interior decor, brass fixtures, and large windows give her an inviting feel.

The owner is focused on spending the majority of time outside and in the water which is why the lazarette area is a custom dive area with storage for masks/fins/wetsuits/multiple Sea Bobs with the highlight being a Nitrox dive compressor. Quick connect dive tanks fill station on the swim platform and hydraulic dive platform allow easy access into the water both when you are in just a bathing suit or in a full wetsuit & cbd.

She has a best in class sundeck with full bar, bbq, jacuzzi, lounge area & dining/sitting area.

Both the aft deck and upper aft deck space has formal dining spaces with tables that seat up to 12 guests.

She has been professionally maintained since new with a full time crew.

Privately owned her entire life she would also do extremely well on the charter market.

2020-2021 Refit


  • Shafts were removed & upgraded with higher quality product under the advice and supervision of CdM Shipyard.
  •  Stabilizers fully serviced with new seals.
  •  RINA 5 Year Class Survey Completed
  • All the valves removed, pressure tested, inspected by Rina
  • All cooling piping and manifolds removed and cleaned.
  • Alpha-laval pump- complete strip and rebuild
  • Sanitation system rebuild and serviced
  • All pumps removed and sent in for rebuild and service - 2 x Fresh water pumps, 2 x AC raw water pumps, 2 x AC fresh water cooling pumps
  • Both Water makers service done ( oil change and restoration of systems) by Aqua tech including replacement of all membranes, and filter and UV lamp system
  • Major AC ducting and blower cleaning done for the entire system by BlueStar marine
  • Upgrade of the networking system by K4.
  • Bridge navigation pc replaced and set up with Time zero Professional that is linked up to the Nav net
  • Both navigation systems are linked into the autopilot system.
  • Bridge navigation systems can be remotely monitored.
  • All digital publications and digital charts up to date.
  • Gyro 5 year service done along with replacement of pump.
  • Both anchor Windlass stripped, cleaned, seals replaced, brake pads replaced along with oil change.
  • Vessel buffed and waxed with 3 coats.
  • Medical kit upgrade to Offshore by MSOS
  • On going maintenance on DeepBlue system

Main engines:

  • Heat exchangers were replaced with new units on Port and Starboard and the gear cooler was chemically cleaned on both engines.
  • All rubber hoses were replaced along with their clamps on both engines.
  • Valve clearance done.
  • Inspection of fresh water and raw water pumps on both engines - only starboard main engine raw water pump replaced.
  • The cooling system was flushed a number of times before final top up on both engines.
  • Rebuild of both main engine alternators done.
  • Both main engines oil samples done along with a full diagnostic done by the Cat agents on the engines. (July 2021)
  • MCCDAQ.com system installed with 8 sensors on the heat exchanger lines that can be monitored in the bridge.

Generators:

  • Port and starboard Generators valve clearance done
  • Replacement of raw water pumps
  • Flushing of heat exchangers replacement of leaking sump plugs, exhaust piping along with clamps changed.

Deck Equipment


Docking Capstans - MIUR VR 4000

Vertical Windlass - MIUR VRC 4500

Anchor - 2 x 225 Kg (2 x 496 pound)

Anchor Chain - 2 x 137.5 mt, diametro 14 mm (2 x 451 ft, diameter 0,55 inches)

Gangway - Electro-hydraulic Bitecnomare “Magnum due” : 5,3 mt X 0,6 mt (17.4 ft x 2 ft)

Crane -Sanguinetti (2000 Kg max load

Appliances




Galley

  • AEG Induction hob HK874400FB
  • Miele dishwasher speed plus PG8056• Nr 2 Miele ed/cs fridge k 14820 sd
  • Miele hood da 3490
  • Nr 2 MKN Combi oven Junior



Dinette

  • Miele Microwave 6022SC
  • Miele ed/cs fridge k 14820 sd
  • Miele Freezer FN12827
  • Miele washing machine WKH130• Miele tumble dryer TKG450 WP



Lazarette

  • Miele washing machine WKH130• Miele tumble dryer TKG450 WP



Sun Deck

  • LYNX gas bbq Grills 27”
  • Isotherm Drawer Box DR 105 L Inox • Isotherm ice maker ice drink clear



Upper Deck Cockpit

  • Isotherm Drawer Fridge DR 85 Inox



Main Deck Cockpit

  • Isotherm Cruise 90 Freezer inox
  • Isotherm Ice maker ice drink clear inox • Isotherm Drawer Box DR 105 L Inox

Entertainment System


Main Salon

  • TV LED Samsung (55”) + TV lift
  • Denon amplifier
  • Kit Bose 5 and subwoofer
  • Denon DVD Bluray player
  • Console Sony Playstation 4
  • Sonos connect
  • iPad Air 128 GB
  • Dock station iPad Air
  • Apple TV
  • Telephone Jacob Jensen



Owner Cabin

  • TV LED Samsung (46”)
  • Sonos playbar
  • Sonos subwoofer
  • iPad Air 128 GB
  • Dock station iPad Air
  • Apple TV
  • Telephone Jacob Jensen



Sky Lounge

  • TV LED Samsung  (55”) + TV lift
  • Denon amplifier
  • Kit Bose 5 and subwoofer
  • Denon DVD Bluray player
  • Console Sony Playstation 4
  • Sonos connect
  • iPad Air 128 GB
  • Dock station iPad Air
  • Apple TV
  • Telephone Jacob Jensen



VIP Cabin STB

  • TV LED Samsung (40”)
  • Denon amplifier
  • 2 x Bose speakers
  • iPad mini 128 GB
  • Dock station iPad Mini
  • Apple TV
  • Telephone Jacob Jensen



VIP Cabin PTS

  • TV LED Samsung (40”)
  • Denon amplifier
  • 2 x Bose speakers
  • iPad mini 128 GB
  • Dock station iPad Mini
  • Apple TV
  • Telephone Jacob Jensen

Guest Cabin PTS

  • TV LED Samsung  (22”)
  • Denon amplifier
  • 2 x Bose speakers
  • iPad mini 16 GB
  • Dock station iPad Mini
  • Apple TV
  • Telephone Jacob Jensen



Guest Cabin STB

  • TV LED Samsung  (22”)
  • Denon amplifier
  • 2 x Bose speakers
  • iPad mini 16 GB
  • Dock station iPad Mini
  • Apple TV
  • Telephone Jacob Jensen



Dinette

  • TV LED Samsung  (22”)
  • Denon amplifier
  • 2 x Bose speaker
  • iPad Air 128 GB
  • Dock station iPad Air
  • Apple TV



Captain Cabin

  • TV LED Samsung  (22”)
  • Denon amplifier
  • 2 x Bose speaker
  • iPad Air 128 GB
  • Dock station iPad Air
  • Apple TV
  • Telephone Jacob Jensen

Wheelhouse

  • Bose Soundlink Bluetooth
  • Telephone Panasonic / display LCD
  • Galley



Lazarette

  • Sonos Connect amplifier
  • 4 x JL speakers
  • iPad mini 16 GB
  • Telephone Jacob Jensen



Main Deck Cockpit

  • Sonos Connect amplifier
  • 2 x JL speakers
  • iPad mini 128 GB



Upper Deck Cockpit

  • Sonos Connect amplifier
  • 4 x JL speakers + subwoofer
  • Upper deck foredeck
  • Sonos Connect amplifier
  •  2 x JL speakers



Sun Deck

  • Sonos Connect amplifier
  • 4 x JL speakers + subwoofer
  • iPad mini 128 GB



Wi-Fi

  • Cisco switch 24 port
  • Nr 6 Access points

Navigation And Communication Equipment


  • (4) Furuno monitor 19”
  • (1) Radar Furuno FAR2117, radome 8 ft, X band
  • (1) Radar Furuno Navnet 3D MFDBB
  • (1) MPU, radome 6 ft
  • (2) GPS Furuno GP-33
  • (1) Furuno trasducer 525ST
  • (1) Data repeater FI-501
  • (3) Data repeater FI-504
  • (1) wind sensor FI-5001
  • (1) Furuno Satellite Compass SC50
  • (1) Furuno AIS FA150
  • (1) Furuno Navtex NX700B
  • (2) Furuno Data Repeater FI-504 for crew mess
  • (1) NAVNET TZT 9”
  • (1) monitor for TVCC, Neovo X-15AV
  • (1) Transas ECS SW NAVISAILOR 4000
  • (1) Raytheon Anshutz Gyrocompass Standard 22
  • (1) Raytheon Anshutz NP60
  • (1) Radio telephone VHF FURUNO
  • (1) FM8900S GMDSS Class A
  • (1) Radio telephone VHF FURUNO
  • (1) FM-4721,DSC
  • (1) FLIR M-618CS

Cctv System


  • CCTV camera on engine room and main deck
  • CCTV monitor in wheelhouse and crew area

Antennas


  • (1) Satellite Antenna VSAT Intellian T100W (1.05 mt, 3.4 ft)
  • (1) Satellite Antenna TVSTAT Intellian V100GX
  • GSM antenna
  • FM receiver

Other


  • Movable swimming platform: Transformer Opacmare 4 steps / 980 Kg
  • Nr 20 underwater lights
  • Nr 4 wind stopper doors
  • Wind protective awning for main deck (Norvegese)
  • Skylight glass on sun deck with motorized curtain
  • Plug-in shower on swimming platform • Diving compressor
  • Sea chests Cathelco anti fouling system
  • Sun deck aft awning
  • Upper deck aft awning
