Off Market
UNIQUE AND EXCLUSIVE YACHT
LOWER PRICE IN THE MARKET
EXTRAS OPTIONALS 800K USD
MAN V12-1800 - 2 x 27KW ONAN GENERATORS
WARRANTY STILL IN PLACE
FULL EQUIPMENT
MARINA FULL PAID UNTIL MAY 2019, IN BARCELONA/ SPAIN.
Located immediately on the stern side of the wheelhouse, on the port-side of the main deck, it can be accessed via the hidden sliding door. It features:
Located immediately on the stern side of the dashboard, it is horizontally aligned with the day toilet and it can be accessed via a hidden sliding door via the saloon or via the external starboard side walkway via the side door. This configuration makes the galley completely close off from surrounding areas. The galley includes:
The main below deck areas (accommodation areas) beginning at the stern:
• Crew Areas
• Engine room
• Master Cabin and Lobby
• Corridor
• Starboard Guest Cabin
• Port-side Guest Cabin
• VIP Cabin
• The master cabin and relative head are equipped with a small lobby.
The equipment areas are located at the furthest stern point and are equipped with separate entrance (stern swim platform).
At full beam, located at the stern of the master cabin, it is divided into two by the presence of the large shower:
Located at the farthest bow below deck, it can be accessed using the central corridor and includes:
Located at stern, they are divided into:
• Captain’s cabin on the starboard side, equipped with single bed
• Crew cabin on the port-side, equipped with single bed but with the option of installing an additional bed
Both Cabins Feature:
In the corridor, available to both cabins, can be found:
Shared bathroom with access door located on the corridor and which features:
On board voltages are as follows:
The main electrical boards are installed according to the following configuration:
Emergency Control Panel: positioned on the starboard side of the dashboard
Battery isolator/Emergency/Fire protection Control Panel: positioned in the cockpit, on the port-side in consideration of the saloon entrance
Derivation boxes are located in all areas
2 single-phase generator 20 kW/230 Vac - in engine room
AC energy sources go back to the main electrical panel positioned in the engine room, equipped with Voltmeter and Ammeter for the 220 V network. Energy sources are protected by suitably calibrated fuses
Water-based system, WORLD Version
Distribution:
A/C derivation in the heads: every cabin serves the relative head. Every room has its own control panel making it independent.
Engine cooling system: includes 2 sea intakes with 4” filter and valve (1 per engine) which
serve to cool:
Generator cooling system : includes 1 sea intake with 1” filter
Conditioner cooling system: 1” 1 /2 sea intake with filter
Chain washer and fire protection: 1 sea intake with 1” filter
Head aeration: by means of 24 V extractors, specifically:
Engine room:
Flap system: made up of 2 Aisi 316 poles with diameter of 800x700 mm driven by an hydraulic cylinder, a 24 V electro-hydraulic control panel
Walkway system: mod. 1103/45, with 3 sections positioned on the right side of the ship, MAX load of 150 kg, max. extended length 4,500 mm, driven by 24 V electro-hydraulic control panel
Platform lifting mechanism: complete with stainless steel frame, MAX net load of 1,000 kg, driven by 220 V - 50/60 Hz electro-hydraulic control panel
EXTRAS OPTIONALS included 800K USD:
