38' Alajuela 1976 Nefer-Ra

Long Beach, CA, US

Previously Asking $87,777

Off Market

Description



New bottom paint

New topside paint & bright work

New teak in cockpit

New bowsprit

New engine and generator in 2002

New standing and running rigging in 2002

Custom Dive platform and tank storage

Custom permanent "Hard Dodger"







Yacht Overview


  • Yacht Details 38' Alajuela 1976
  • Location Long Beach, CA, US
  • Engines
  • Beam 11' 6''
  • Draft 5' 7''
  • Staterooms 1

Specifications

  • Beam: 11' 6''
  • Hull Material: Fiberglass
  • Max Draft: 5' 7''
  • Displacement: 27,000 lb
  • Fuel Tank: 1 x 75 gal
  • Fresh Water: 1 x 100 gal
  • Holding: 1 x 27 gal
  • Cabins: 1
  • Heads: 1

Accommodations

Accommodations
  • Berths for five with pilot berth in salon to port and "V" forward. Full galley: 2 burner AC stove top, microwave, sink, and ice box. Enclosed head with manual toilet with "Y" valve, sink, shower wand. Engine compartment under cockpit/companionway.

Construction

Construction
  • Hull:  Fiberglass hand laminated FRP in a two-piece mold
  • Deck: hand laminated FRP,marine plywood cored, applied non-skid
  • Cabin: hand laminated FRP molded with deck, marine plywood cored
  • Keel: molded with hull, integral cast lead ballast
  • Rudder: solid FRP, bronze pintles and gudgeons
  • Cabinetry: teak & teak plywood, teak & holly soles
  • Rig: painted aluminum mast and boom, keel stepped mast





Description

Description
  • Hull color: white
  • Bow: spoon with sprit   Stern: double ended  Sheer: conventional
  • Hull: round bilged, low wetted surface
  • Keel: full profile, wineglass sections, slack bilges
  • Rudder: outboard, full keel swung
  • Cabin: long trunk, aft cockpit with high coamings
  • Rig: single spreader masthead Marconi cutter, bow sprit

Engines

Engines
  • PROPULSION: Westerbeke 3 cyl. 35 hp.diesel  Model# 35C Three JS fresh water cooled, wet exhaust engine compartment under companionway/cockpit. Manual reverse/reduction marine gear. 17" Max Prop 3 blade feathering bronze propeller.      1 1/4" stainless steel shaft.
  • AUXILIARY GENERATOR: Westerbeke 3 cyl. 5.0 KW diesel/120v.AC  Model# 5.0BGDE  fresh water cooled, aft in engine compartment.

Electrical

Electrical
  • 12 volt DC system and 120 volt AC ship/shore power system 5 group 27 L/A 12 volt batteries. All batteries properly boxed, secured and ventilated with fused switch panel.
  • Navigation, cabin, and spreader lights, portable spot light, marine multi-bank battery charger, AC volt meter, AC and DC ammeters AC fresh water heater, DC Watermaker.

Safety

Safety
  • 3 - 2.5 lb. dry chemical fire extinguishers.
  • 5-  approved type personal flotation devices.
  • 1- Type IV throwable device, lifesling bow and stern pulpits, double lifelines, handrails horn and bell, flare kit.

Ground Tackle

Ground Tackle
  • 45 CQR plow anchor
  • 300' chain, 10' line (est.)
  • 45 lb. plow spare anchor
  • Electric windlass

Sails

Sails
  • Main
  • Yankee
  • Stays'l
  • 150% Genoa

Other

Other
  • Custom FRP Permanent "Hard" Dodger
  • 6" Ritchie Compass
  •  Roller Traveler
  • Rigid Boom Vang
  • S.S.Barbeque

    Winches (all Barient):

  • 2 -28 STS primary
  • 3 -22 S halyard
  • 3 -23 STC multi-purpose
  • 2- cabin top



Special Note

Special Note

A complete rehab of the vessel was conducted in 2002 including the new engine and generator, all new wiring and panels, removal of the teak deck overlay and re-glassing the entire deck and cabin structure, installing cockpit seat hatches with lockers. The rig was refurbished including painting the mast and boom and replacing all standing and running rigging.
