36 Beneteau 2023 Boat for Sale

 DIMENSIONS

• L.O.A.  39’4’’

• Hull length  36'1"

• L.W.L.  33'8"

• Beam  12'6"

• Light displacement (MLC*) 10580 lbs

• Standard keel weight   3420 lbs

• Standard keel draft   7'5"

• Engine power (sail drive)   29 HP

• Fuel capacity   18.5 gal

• Fresh water capacity   50 gal

 RIG & SAILS

• Mast length   50'10"

• Air draft (excluding antennae)   58'5"

• Sail area upwind   861 sq ft

• Sail area downwind   1970 sq ft

• Mainsail (maximum area)   452 sq ft

• Jib (maximum area)   409 sq ft

• Masthead gennaker (maximum area)   1518 sq ft

• Fractional furling gennaker  780 sq ft

EC Certification

• A6/B8/C10

ARCHITECTS & DESIGNERS

• Naval Architecture: Samuel MANUARD

• Design: Lorenzo ARGENTO

• Structural Engineering: Pure Design & Engineering

• Interior design: SITO

• Concept and R&D: BENETEAU & Seascape

• The entire boat structure is built in vacuum-infused fibreglass with vinyl ester resin

• Fully cored hull with Corecell core and hand-laid vinyl ester skin coat

• Moulded and vacuum-infused bulkheads with Mycell (PVC) core

• Fully cored vacuum-infused interior modules, designed to serve as the boat’s structure and furniture

• Fully cored deck with a moulded, non-slip surface

• White single-tone gelcoat

• Aluminium mast support

• Cast iron keel with low drag fin and T-bulb; draft 2,25 m / 7’ 5’’, weight 1550 kg / 3420 lbs

• Twin vacuum-infused composited rudder blades with stainless steel stock

• Deck-stepped tapered Z Spars 9/10 aluminium mast with two sets of swept-back aluminium spreaders

• Z Spars aluminium boom

• Linked standing rigging with Dyform wire and bottle screw adjusters

• Central Robline STS Dyneema spliced blocks and tackle backstay with control lines lead to both steering wheels

• Windex 15

• Robline high-performance halyards (Dyneema cores with polyester covers): mainsail, jib, masthead gennaker, masthead Code0 2:1

• 3x Ronstan Trigger Snap Shackles for masthead gennaker & jib halyards and tackline

• Spinlock XTS halyard clutches on the coachroof

• Coachroof winches: 2x 40 Harken Self-Tailing Performa Winch

• Robline high-performance running rigging (Dyneema cores with polyester covers): jib & mainsail & gennaker sheets, two mainsail reefs, two tacklines, other control lines

• Primary winches: 2x 46 Harken Self-Tailing Performa Winch

• Harken blocks and deck equipment for mainsail, jib and gennaker controls

• Harken aluminium 5:1 mainsail traveller system with dedicated mainsail sheet winches: 2x 40 Harken Self-Tailing Performa Winch

• Adjustable jib in- and down-haulers for precise 3D trim of the jib

• Wichard folding padeye aft of the anchor locker for the staysail deck attachment

BOWSPRIT WITH ANCHOR SYSTEM

• Vacuum-infused GRP bowsprit in black, length 0,98 m / 3’ 3’’

• Integrated stainless steel anchor crane and roller with rigid stainless steel bobstay

• Lewmar Delta galvanised anchor (16 kg / 35 lbs) with 50 m/8 mm / 164 ft/5⁄16” chain

• Quick Prince DP2 Windlass (12V 700W) with handheld remote control and magnetic circuit breaker

FACNOR FLATDECK FD190 FURLER

• Facnor FlatDeck FD190 furler with furling line

• Furling line jammer and block in the cockpit

• in lieu of standard jib tack attachment

BARTON RODKICKER/BOOMKICKER

• Barton lightweight fibreglass boomkicker

HALYARDS UPGRADE PACK

• Additional fractional gennaker, jib and staysail halyards

• Robline high-performance ropes with Dyneema cores and polyester covers

• 2x Ronstan Trigger Snap Shackle for fractional gennaker and jib halyard

• Additional Ronstan blocks at the mast base

• Stainless steel stanchions (60 cm / 2’’ high) with double lifelines

• Aluminium mooring cleats on the bow, stern and beam

• Jefa steering system with two composite steering wheels in black

• Stainless steel grabrails on the top of each steering console, with one carbon GRP console and Silva 85E compass

• Stainless steel grabrail on each side of the coachroof

• Moulded GRP toerails front and aft of steering wheels for helmsman and crew

• Four Outils Océan bags with dedicated rope & winch handle pockets, two at the jib trimmer position & two at the cabin entrance

• Two Harken winch handles

• Anchor locker with a hatch

• Stowage compartments for two gas bottles under the port helmsman bench

• Storage compartment under the starboard helmsman bench with breathable storage bag

• Spacious storage compartment with hatch below the aft cockpit floor between the steering wheels; also for life-raft stowage

• Monolithic GRP autopilot bracket glued on the aft bulkhead

• Lightweight foldable bathing platform, built-in HoneyComb technology, with a lifting system

• A foldable and telescopic bathing ladder on the side of the bathing platform, also used as means of reboarding

SALOON

• Headroom: 1,88 - 1,80 m / 6’ 2’’ - 5’ 11’’

• Lightweight vacuum-infused GRP interior (saloon benches, galley, icebox, navigation table) with low-maintenance gelcoat finish

• Central table island (coffee table), with foldable table flaps (plywood, Alpi teak wood veneer)

• Laminated Alpi teak wood veneer fiddles (railing edge) around the galley, icebox, navigation table and central table island

• Floorboards made of plywood with durable teak imitation

• Extremely light deck liners (moulded GRP, mat finish) and side liners (covered in textile)

• Laminated tempered glass windows on both sides of the hull and the sides of the coachroof

• Lewmar Flush Hatch 3G (60 cm x 60 cm / 24” x 24”) above the saloon table and two Lewmar Flush Hatch 3G (21 cm x 40 cm / 8” x 16”) above the galley and navigation table

• Wooden companionway stairs, closing the access to the engine compartment

• Horizontal sliding plexi panel, with dial combination lock

• Plexi companionway washboard in three parts – foldable bottom piece and two removable panels

• Comfortable cushions for saloon benches in light grey

• Indirect LED lights for different light setups around the ceiling edge, behind the deck inner liner edge and under the benches. Additional red LED lights behind the deck innerliner for night sailing.

GALLEY

• L-galley on the port side of the saloon

• Eno gimbaled gas marine stove (2 burners) with oven

• Gas installation with safety tap

• Galley working surface covered with Kerrock solid surface material

• Cupboards above the galley (plywood, Alpi teak wood veneer)

• Bottles storage next to the stove

• Single rectangular stainless-steel sink with a freshwater tap & plumbing

• Trash bin next to the sink, with the top opening

• Locker with drawers below the sink (three drawers, white plywood covers)

• Central top-loading icebox (70 L / 18,5 US Gal) with inspection hatch at the bottom

NAVIGATION TABLE

• Navigation table on the starboard side of the saloon

• Chart compartment with top opening

• Wooden doors (plywood, Alpi teak wood veneer) with light switches, electric control panel and other optional electronics

• Reading spotlight in white or red

• 2x USB-A & 2x USB-C & 2x 115V sockets

• Installation of all main electric systems, controls and fuses behind and under the navigation table

FRONT CABIN

• Headroom at the entrance: 1,87 / 6’ 1’’

• Comfortable V berth (2,02 m x 2,00 m – 0,80 m / 6’ 7’’ x 6’ 7’’ - 2’ 7’’) with cushion

• Locker with shelves & hangers (plywood, Alpi teak wood veneer), with fiddle on the top

• Storage compartments under V-berth and locker

• Shelve with fiddle (plywood, Alpi teak wood veneer) along both sides of the cabin

• Indirect LED lights along the deck’s inner liner edge

• Two reading spotlights with integrated USB-A sockets

• Lewmar Low Profile hatch (60 cm x 60 cm / 24” x 24”) above the berth

• Lewmar Flush Hatch 3G (21 cm x 40 cm / 8” x 16”) above the entrance

AFT CABINS - PORT & STARBOARD

• Headroom: 1,90 / 6’ 3’’ at the entrance

• Comfortable berth (2,02 m x 1,35 m / 6’ 7’’ x 4’ 4’’) with cushion

• Innovative removable bed slats for the inside berth, enabling easy access to the storage space underneath or its easy removal

• Locker with shelves & hangers (plywood, Alpi teak wood veneer), with top fiddle

• Shelve with fiddle (plywood, Alpi teak wood veneer) along with the cabin with indirect LED lights

• Two reading spotlights with integrated USB-A sockets

• Openings to storage space underneath the outside berth

• Lewmar Flush Hatch 3G (21 cm x 40 cm / 8” x 16”) above the entrance

• Lewmar Portlight openings towards the cockpit with removable mosquito nets

HEAD

• Headroom at the entrance: 1,86 / 6’ 1’’

• A compact and innovative head compartment

• Light-weight vacuum-infused GRP interior with low-maintenance gelcoat finish

• A floor in moulded nonskid surface with shower bilge pump

• Innovative foldable GRP sink above the toilet, Barka tap with shower handle

• Locker above the sink with mirror

• Manual Jabsco toilet with black water tank (50 L / 13,2 US Gal) & plumbing

• Lewmar Flush Hatch 3G (21 cm x 40 cm / 8” x 16”) above the entrance for ventilation

AUDIO PACK (FUSION MARINE STEREO)

• Fusion MSRA210 FM radio with Bluetooth connectivity, installed at the navigation table

• Four Fusion XS40 waterproof speakers (4-inch, 120 W), two in the cockpit and two in the saloon

GARMIN OFFSHORE PACK

• Two GMI 20 large and bright 4’’ QVGA colour displays with LED backlighting, installed one below each jib & gennaker trim winch

• Airmar DST810 depth, speed and temperature transducer

• gWind race wired wind transducer on 1 m / 3’ 3’’ high pole

• Three GNX 120 high-precision backlit LCDs with bold 51 mm / 2’’ digits, installed on the bracket under the boom

• VHF 215i with VHF antenna, compatible with USA requirements

• GA 38 GPS/GLONASS antenna

• Entire Garmin Coastal pack

• GHP Reactor™ 40 Autopilot System

• CCU Corse Computer Unit with Solid-state 9-axis Attitude Heading Reference System (AHRS)

• ECU Electronic Control Unit

• GHC 50 4’’ touchscreen colour displays for autopilot control installed to black GRP console in front of port steering wheel

• Reactor™ Autopilot Remote Control

• Raymarine mechanical linear drive, Type 1, providing minimal friction on the tiller when dis-engaged

• Dedicated switch for an autopilot on the control panel

GARMIN CHARTPLOTTER

• GPSMAP 923 touchscreen chartplotter with high-resolution IPS display

• Installed on starboard steering wheel grabrail with carbon GRP plate

• Supplied with Worldwide Base map, without detailed charts!

• Garmin Sailassist™ sailing features

GARMIN AIS 800 TRANSCEIVER with LITHIUM BATTERY

• Garmin AIS 800 Blackbox Transceiver, including VHF antenna splitter

• Additional lithium battery in navigation table cupboard, high above the sea level for completely autonomous Class-A compliant AIS & VHF system

PLUMBING

• 2x 100 L / 26,4 US Gal rotomoulded freshwater tanks under the saloon benches

• 12V pressurised fresh water system

• Plumbing with taps in the galley and head

• Corrosion-free Trudesign plastic thru hulls and valves

• Electric & manual bilge pump

ELECTRICITY

• Simarine customised control panel of 12V & 230DC circuit with fluids indicators screen, installed at the navigation table

• 12V electric circuit and 2 x 12V 105 AH AGM service battery, installed under the icebox

• 115V installation with 30A battery charger and magnetic circuit breakers

• 2x 115V sockets under the navigation table

• Shore power cord with cockpit socket

• Indirect LED lights & spotlights; see each room for details

• Masthead LED navigation, steaming and anchor lights
