39 Beneteau 2024 Boat For Sale

General Specifications*

• L.O.A: 11,93m - 39’2’’
• Hull length 10,99m - 36’1’’
• L.W.L. 10,83m - 35’6’’
• Beam 3,92m - 12’10’’
• Deep draft (Cast iron) 2,10m - 6’11’’
• Deep ballast weight 1 800kg
• Shallow draft (Cast iron) 1,63m - 5’4’’
• Shallow ballast weight 1 970kg
• Air draft (all masts), with aerial 16,60m - 54’6’’
• Light displacement 6 864kg
• Fuel capacity (standard) 130L
• Fresh water capacity 355L
• Engine power 40 HP

Architects / Designer

• Naval Architect: Marc Lombard
• Outside & interior design: Nauta Desig

EC Certification*

• Category A - 8 people
• Category B - 10 people
• Category C - 10 people

Standard Sails Dimensions*

• Classic mainsail (standard) 37m²
• Furling mainsail (option) 31m²
• Self-tacking jib (standard) 23m²
• Furling 110% genoa (option) 30m²
• Code 0 (option) 53m²
• Asymmetric spinnaker (option) 95m²
• Classical mast:

            - I           13,51m (44’4’’)

            - J           4,33m (14’2’’)

            - P          13,75m (45’1’’)

            - E          4,50m (14’9’’)

• Roller furling mast:

            - I           13,43m (44’1’’)

            - J           4,33m (14’2’’)

            - P           13,90m (45’7’’)

            - E           4,80m (15’9’’)

Performance Sails (Option - Requires classical mast)

• Square top mainsail 42,50m²
• Genoa (on Flatdeck furler) 31m²

* Provisional specifications, boat in process of certification.

Construction

• Design in accordance with European Directive requirements and according to CE certification
• Monolithic hull design in polyester
• Monolithic structural inner moulding bonded to the hull
• Injected deck construction in glass fiber and Saerform foam sandwich, covered with non-slip diamond pattern
• Hull-deck join screwed, bonded and trimmed with 1 bulwark
• Cast iron keel fixed with bolts and stainless steel backing plates
• 2 Underhung rudders with stainless steel stock
• White coloured hull - Grey metal hull graphics
• 4 Hull portholes

Rigging

• Standard mast 9/10 anodized aluminum deck stepped, 2 aft-swept spreaders - Without backstay (Z-Diffusion) - Without backstay
• Anodised aluminum boom
• Discontinuous stainless steel standing rigging
• Rigid boom vang with tackle
• Self-tacking jib rigging with on-deck furler
• Mainsail stay rope on the roof (with 2 chainplates)
• 1 Self-tacking jib track with traveller
• Complete running rigging: Mainsail halyard, Genoa halyard with cleat on mast, Boom topping lift with cleat on mast, Mainsheet, 1 Self-tacking jib sheet
• 8 Clutches
• Winch feeder to starboard from the companionway
• 2 Flag halyards

Winches

• 1 Self tailing winch (H35.2 STA) to port, on the coachroof
• 1 Aluminum "Speed Grip" winch handle
• 1 Winch handle box

Sails (Elvstrom)

• Classic Dacron C-breeze mainsail with Natural UV protection, cross cut, semi full batten
• Self-tacking jib Dacron C-breeze with UV protection Natural, horizontal cut

Mooring Lines - Mooring

• Self-draining chain locker - Clench bolt - Hatch cover
• Single stem roller
• 6 Aluminum mooring cleats - Stainless steel chafing plate

Safety on deck

• 1 Stainless steel pulpit 2 sections
• 2 Stainless steel pushpits
• 1 Lifebuoy support bracket
• Double guard lines and stainless steel stanchions
• Welded ring on pushpit for flag
• Emergency ladder

Cockpit

• Self-draining cockpit
• 1 Cockpit locker beneath starboard bench
• Side helm's seats (aft helm seats in trim)
• 1 Liferaft locker to aft of cockpit (Usable dimensions: 830mm x 545mm x 380mm / 2’9’ x 1’9’’ x 1’3’’)
• Iro-Deck slatted cockpit benches (1,75m x 0,52m / 5’9’’ x 1’8’’)
• Polyester drop-leaf cockpit table, Stainless steel handrail
• Tilling positon: Stainless steel steering wheels - 800mm diameter / 2’7’’ - Leather covered - Steering gear at the helm station - metal cable transmission system - Stainless steel handrail - 1 Cup holder
• 1 Steering compass, to starboard, at steering station
• 2 Deck access points to tiller system
• 1 Emergency tiller
• Engine throttle and control panel on starboard
• 2 Hinged PMMA companionway doors - Sliding hatch made of PMMA
• 1 Fixed, telescopic stainless steel swimming ladder

Swim Platform / Aft Transom (in tim level)

• Fully opening transom, convertible to bathing platform (2,69m x 0,77m / 8’10’ x 2’6’’)
• Manual opening with hoist
• Iro-Deck slatted swim deck
• 1 Stainless steel fixed swimming ladder with handrails

Interior

• Alpi walnut woodwork
• Rovere Aleve type laminated floorboards
• Beige padding upholstery: Saloon
• Neo 05 fabric interior upholstery
• Mattresses in the cabins, HR35kg/m3 foam

Companionway

• Headroom: 1,92m / 6’4’’
• Wood saloon companionway
• 1 Stainless steel handrail to port with cognac leather cover

Saloon - Port

• Headroom: 1,92 - 1,88m / 6’4’’ - 6’2’’
• U-shaped saloon bench seat - double density foam
• Saloon table, wooden top, 2 fixed aluminum legs
• 1 Storage cupboard with shelves, 2 doors
• Storage under bench seats
• 2 LED ceiling lights
• 2 Panoramic roof windows
• 1 Porthole (blinds optional)
• 1 Flush deck hatch with fan, T44, blind and mosquito net
• 1 x T10 deck hatch (330 x 140mm / 1’1’’ x 6’’) to port

Lengthways Galley Counter - Starboard

• Headroom: 1,91m / 6’3’’
• Compact Clay worktop with Corian toe rails
• 1 rectangular stainless steel sink (352 x 322 x 170mm / 1’2’’ x 1’1’’ x 7’’)
• Mixer tap with hot/cold water under pressure
• 1 Gas cooker 2 burners - Stainless steel oven on gimbal - Stainless steel protection handrail
• Cool box 160 L top opening (Positive cold)
• Storage and lockers
• 1 x 26 L bin
• 1 x 230 V socket (in trim level)
• 1 Porthole (blinds optional)
• 1 x T10 deck hatch (330 x 140mm / 1’1’’ x 6’’)

Port Side Chart Table

• Headroom: 1,92m / 6’4’’
• Fixed table with stowage under the tabletop - Wooden toe rail
• Switch panel on bulkhead for access to electrical functions
• 1 LED spotlight
• 1 x 230 V socket (in trim level)
• 1 Single USB socket, on the electrical panel
• 1 Opening porthole in coaming

Owner's Cabin

• Headroom: 1,89m / 6’2’’
• Central double bed (2,07m x 1,61m x 0,90m / 6’9’’ x 5’3’’ x 2’11’’)
• 2 Hanger closets, Open storage compartment along the hull
• 2 Adjustable LED spotlights in the headboard, 2 on the hanging lockers
• 1 dual USB port, at the head of the bed (in trim level)
• 1 x 230 V socket, to port (in trim level)
• 1 Flush deck hatch with fan, T44, blind and mosquito net
• 2 Hull portholes with curtain
• Door of access

2 Symmetrical Aft Cabins

• Headroom: 1,90m / 6’3’’
• 1 Double bed (2,00m x 1,50m / 6’7’’ x 4’11’’)
• 1 Hanging locker
• 2 Adjustable LED spotlights in the headboard
• 1 dual USB port (in trim level)
• 1 x 230 V socket (in trim level)
• 1 Opening porthole below cockpit seat with curtain (Mosquito net in trim level)

Aft Starboard Head Compartment

• Access through saloon
• Headroom: 1,90m / 6’3’’
• Shower with shower curtain - Self-draining stowage tray - 1 shower function mixer tap - White polyester shower tray
• 1 Manual toilet
• 1 x 80 L rigid holding tank
• 1 Polyester basin - 1 Hot/cold water mixer tap
• 1 Cabinet
• 1 Mirror on bulkhead
• Toilet accessories
• 1 Opening porthole in coaming
• 2 LED ceiling lights

Electricity

• 12V circuit
• 1 AGM service battery (95Ah) - 1 AGM engine battery (50Ah)
• 1 Power distributor
• 12 V electrical panel (Fuses - Voltmeter - 1 Fuel gauge - 1 Navicolor 2’’4 screen)
• 12 V electrical panel
• 1 Single USB socket, at chart table
• LED lighting: Overhead lights with switch, Adjustable spotlight in cabins & at chart table
• LED navigation lights: 1 Masthead light - 1 Engine navigation light - 1 Anchor light on masthead

Engine

• Engine Yanmar Diesel (Propeller shaft): 40 HP Sail Drive (standard)
• Engine control - Control panel in cockpit (to starboard)
• Engine compartment: Soundproofing foam
• Ventilation: 2 air inlets and 2 forced air outlets
• 1 Alternator (12V / 125Ah)
• 1 Rotomoulded diesel tank 130 L (below aft starboard cabin berth)
• Gauge at the chart table
• 1 Deck filler
• Filters: Seawater - Diesel - Water separator - Stainless steel shaft line
• Fixed three blades propeller (standard)
• 1 Engine access through companionway (opening with 2 gas struts)
• 4 Access to side engine

Plumbing

• 1 Rotomoulded freshwater tank 330 L
• Electrical gauge on 12 V panel
• 1 Deck filler
• Pressurised electric water pump - Expansion tank - Inline filter
• 25 L Electric water heater (engine use) behind the engine
• 1 Rigid 80 L black water holding tank for each WC
• 1 Electric bilge pump - 1 Manual bilge pump
• 1 Electric shower drain pump

Gas

• Gas cylinder locker (25 cm x 27 cm x 40 cm / 10’’ x 1’ x 15’’) - Port aft cockpit
• Regulator and safety tap
• Gas leak detector

Smart Board

• "SEANAPPS" smart technology:
• For monitoring the boat's status and receiving alerts as well as maintenance advice via the associated mobile application
• The type of information collected (GPS position, batteries, engine info, navigation data, etc.) varies according to the boat's configuration

Miscellaneous Items

• Smoke detector
• Cleaning kit: eco-friendly cleaning products kit

Propulsion

• Diesel 3JH40 29KW (40HP) - Standard

Keel

• Deep Cast Iron Keel - Standard

Layout

• 3 Cabins 1 Head - White Oak Alpi

Upholstery

• NEO 05 - Upholstery in saloon

Family Trim Level

• Iro-Deck slatted aft platform
• Iro-Deck slatted helm seats
• Hot/cold water cockpit shower
• Galley: Compact sink cover with cutting board
• Hifi Fusion RA210 + Interior loudspeakers & Waterproof exterior speakers
• Dual USB socket: in the saloon (x 1), in the forward cabin (x 1), in the aft cabins (x 1), Starboard helmstation (x 1)
• Full 230 V system (5 Inside sockets, 1 Shore power socket)
• 40 Amperes battery charger, IBS sensor, Navicolor 3''5 screen
• 1 AGM amperes additional service battery (95Ah)
• Mosquito nets for opening portholes
• Saloon: LED indirect lighting
• Galley: Stainless steel 2 burner oven/grill cooker on gimbal (in lieu of standard)
• Bottle storage under floor
• 1 000 W Electric windlass (Remote control)
• Aft transom protection
• Bow stainless steel protection
• "Luxe" polyester drop-leaf cockpit table
• Outboard engine bracket
• Double berth in saloon
• Galley: Sea water foot pump with cool box draining function
• Saloon & Cabins: Fans

Upwind And Downwind Pack

• Starboard manual (H35.2 STA) rigging winch to replace the winch feeder + 1 Cadet Grey halyard bag
• Polyester bowsprit with integrated anchoring gear and bobstay (for Code 0 and asymmetric spinnaker)
• Asymmetrical spinnaker rigging / Code 0 (sheets, Blocks, Halyards)
• Additional jammers (on the roof for the halyard or on the coaming for the Genoa sheet, depending on the pack)
• Rigging run back to cockpit (except boom topping lift)
• 2 Manual (H40.2 STA) genoa sheet winches + Aluminum "Speed Grip"
• winch handle + Winch handle box
• Genoa sheet tracks on roof with traveller (pulls back the traveller on the self trimming jib rail)
• Genoa sheet on furler, high strength Dacron C-breeze (to replace the standard self-tacking jib)

Offshore Pack - Raymarine

• 1 i70s display at port side helm station
• DST810 Sensor (Log, Speedometer, Temperature)
• Wind Sensor (Windvane, Anenometer)
• Windex Windvan
• Starboard helmstation:

           - 1 Steering console

           - 1 x 7'' Axiom + multi-function touchscreen (GPS, Chart plotter, Card reader -                      Navionics®+ Blank cartography included)

           - 1 Console cover, Cadet Grey

• P70s autopilot + control (to port)
• Chart table: RAY73 VHF, AIS receiver function

Sails

• Lazy bag - Natural + Lazy Jacks

Mooring And Anchor Lines

• Aft Fairleads
• Windlass control in cockpit with chain counter
• Mooring - Anchoring kit

Exterior Layout

• Stainlees steel pivoting davits
• Luxe coachroof sprayhood - Cadet Grey
• Cover for uxe polyester - Wood cockpit table
• Luxe cockpit bimini - Cadet Grey

Human Protection

• Access opnings to port and starboard

Exterior Cushions

• Cockpit cushions dolce 51

Exterior Water Circuit

• Dock Water Inlet

Household appliances

Pre-wiring for 230V 50HZ microwave oven

Toiles

• Electric toilet - Quiet Flush - Starboard aft - Sea water

Electrical Circuit

• Inverter 12-230V 2000VA

Hull

• White hull

Navigation Instruments

• AIS - Raymarine

Opening Glazing Roof Ventilation

• Opening porthole in the cockpit for aft cabins
• Pleated blind for hull portholes in saloon

Exterior Joinery

• IRO-DECK Cockpit floor

Transport

• Transport craddle For keeled boat (long Keel)
• Preparation for cargo transport
