NORDHAVN 57 hull #12 is now available for immediate sale. MV "Lady Pam" is the much preferred symetrical layout with full length walkway along both sides, allowing for ease of access for docking and line handling when berthing. This vessel is an original Australian delivered 240V/50Hz equipped boat, fully documented as an Australian Registered Ship, with all Taxes and Duties fully paid. Comprehensively equipped for offshore cruising, with many recent upgrades to her systems and engineering. Handcrafted by the world's finest shipwrights, her modern, contemporary look provides spacious, luxurious accommodations, yet she maintains a sense of serious determination that will endear her to the most salty traditionalist. The design and construction of an ocean going yacht must gracefully blend structural Integrity, comfort and performance. Incorporation of these qualities into the NORDHAVN 57 design and construction specification, together with the excellent craftsmanship of the PAE team, has resulted in a craft that has been described by experts as "the finest ocean going yacht ever produced under 70 feet". The equipment and components included in the engineering and service systems reflect this design philosophy. An impressively efficient fuel burning rate, demonstrates that this boat is the embodiment of a modern, long distance cruiser enabling you to explore and discover the most vast and remote locations in the world. Whether your desire is to cruise the Australasian coastlines or to make more adventurous passages through the western Pacific or up into S. E. Asia and beyond, you are sure to feel safe and confident while making these memories onboard the good ship "Lady Pam".
Engine - Main propulsion is provided by dual, V-drive CATERPILLAR 3116 model turbo-charged diesel engines. Each engine is directly cooled by closed fresh water loop which rejects heat to a raw water (sea water) loop. Electronic control stations for the main propulsion engines are located in the pilot house, the fly bridge, and the aft deck cockpit. In addition, a portable, hand held controller is provided to connect engine control stations on the port and starboard Portuguese bridges. Dual port and starboard Hydraulic pump controls selectable from both flybridge and pilothouse, powering engine room emergency bilge pump, anchor windlass, anchor chain washdown pump, and stabilizers Port engine, starboard engine and Transfer pump fuel filter audible alarms (Engine room sink with self contained sump tank and pump out and large tool box) Full professional service on both engines by Hastings Deering November 2021. Receipts available
Engine Make - Caterpillar
Number Engines - 2
Horsepower - 350 horsepower
Fuel Type - Diesel
Engine Hours - Port: 3296 Starboard: 4367
Fuel Consumption - 10 gph @ 2400 RPM - 19.7 gph @ 2800 RPM. 24v Fuel transfer pump
Cruise Speed - 8 knots
Propulsion - Counter-rotating dual shaft drive with fixed four blade bronze propellers.
Thrusters - ABT bow thruster with control stations at main helm, flybridge and aft cockpit
Genset - 1 x Onan 17.5 KW 1 x Onan 13.5 KW unit (50Hz)
Fuel - 8300 litres
Water - 1300 litres - Wema tank monitor for fresh water tank. Sea Recovery Watermaker
Dinghy - Orca Centre Cockpit Rigid Bottom Inflatable
Outboard - Yamaha 40HP
Covers - Shade/privacy covers for saloon and Pilothouse windows. Cover for tender and outboard. Aft cockpit shade cover. Deck ventilation hatch covers. Flybridge helm control covers.
Accommodation - SALON With entry from the aft cockpit the spacious saloon has an L shaped couch and a dinette high gloss teak table to the port side perfect for entertaining with friends and family. Opposite on the starboard side are 2 more chairs for seating and a TV and Audio System. Large windows on both port and starboard and aft provide an abundance of natural light. Just forward is the well equipped open planned galley which provides perfect visibility between the cook and family/friends. Sub-Zero bar fridge and LED lights throughout
MASTER STATEROOM
The mast stateroom extends the full width (beam) of the boat providing expanded open areas and cabinet space.
Flooring: Teak and Spruce. Teak bulkheads with varnished teak furniture Cedar lined hanging closets full length mirror and additional reading lights. There is a bathroom to the starboard side offering plenty of room, bench storage space, toilet and full sized shower. LED lights throughout. TV mounted to the wall
VIP STATEROOM
A VIP stateroom is forward boasting an island double berth and a shared dayhead, including a large shower stall, with the guest stateroom to the port side featuring upper and lower bunks. Both rooms have beautiful cabinetry and flooring with storage. LED lights throughout
PILOTHOUSE
Nordhavn quality is abundantly on display in the Nordhavn 57 pilothouse. Commercially inspired features are combined with the type of amenities found on the most luxurious of megayachts. The centerline helm seat provides superior visibility, and within easy reach are the navigation equipment and instrument panel. A settee and table are nearby so that guests can also enjoy comfortable seating as the captain takes command of the yacht. The pilot house also includes a chart table with map light to the port side and custom bookshelves behind the settee and custom cabinets above. Side entry doors with upper and lower windows and direct access to flybridge from pilot house via sliding glass hatch. Overhead ventilation hatch with flyscreen. Individually switched reading downlights. Destroyer type stainless steel steel helm wheel. Stainless steel safety handrail above helm station. LED lights throughout
LAUNDRY
The Laundry System consists of a matched set Meile Washer and Meile washer units both located in a utility room forward of the engine room compartment.
Toilet - 2 HEAD HUNTER toilets in owner and guest staterooms - 1 JABSCO toilet in crew/day head
Entertainment - Fusion Marine MS-RA70N Audio System with Bluetooth capability
JBL speakers
Flat screen saloon TV
Flat screen Master stateroom TV
Air-Con - CRUISAIR remote compressor system. Reverse cycle with heat strips
Galley - With full-sized home-style appliances, abundant storage cabinets and generous counter space, and deep double bowl sink, the galley will please any owner or chef. She has appliances which include a dishwasher, oven and stove and Sub-Zero fridge/freezer. The galley also includes an LG microwave and a convenient garbage compactor and disposal unit. There is an entry via the port side which is ideal for airflow while underway or cooking and preparing meals.
Water-Maker - 800 GPD watermaker - Aqua Whisper (Carbon filter on fresh water system)
Ground Tackle - New 125 metres of 13mm short link Grade galvanised chain Oct. 2021
50kg. AXE type main anchor
Fortress aluminium folding anchor
Maxwell 3500 hydraulic windlass with rope and chain gypsy
Rope hawsepipe in portside deck
Up and down foot switch anchor controls at foredeck
Maxwell remote anchor controls at helm and flybridge
Dual bow rollers
Stern snubbing winch - Maxwell 2200 electric
ARITEX stainless steel hydraulic-electric davit with wired remote
Safety Gear - Portable fire extinguishers for each cabin
FireBoy fixed engine room automatic fire suppression system, with remote panel & manual override
Operational Fixed fire system Certification, February 2022.
Smoke detectors
Horn activated from Helm and Flybridge
2 x EPIRB
Security alarm system
Throwing type lifering
Sea anchor/drogue
Bilge Pumps - 3 x auto electric and 1 x hydraulic emergency main bilge pump
Life Raft - Located on fly bridge
Epirb - Yes
Life Jackets - As per Queensland maritime Regulations
Flares - As per Queensland maritime Regulations
Fire Protection - Portable fire extinguishers throughout and a self actuated fire suppression system in the engine room
Electrics - 2 x ONAN generator sets. 17.5kW and 13.5kW, designed to accommodate all onboard machinery by providing electrical power at voltage levels of 230 VAC 50HZ and 12 VDC.
17.5 Kw 2933 hours. 13.5Kw 5947 hours
2 shore power connections at 2 locations provide the vessel with 230 VAC 50HZ service
9 x 12 VDC house batteries provide power to the DC distribution system
2 x TRACE Pure Sine Wave inverters rated at 2.5 kW each. Chargers the boat's 12 VDC batteries
Vessels electrical system provides AC and DC electrical power service in a complete and conveniently centralised distribution system.
240 VDC outlets with Australian type power points
12 VDC outlets
Interior and exterior lighting throughout the vessel including courtesy lights.
Lightning arrester on Flybridge hardtop
Electronics / Navigation -Raymarine Axiom digital navigation system
Raymarine Hybridtouch digital Multi Function Display at flybridge
2 Raymarine Axiom XL12" Multi Function Displays
2 Raymarine Axiom XL16" Multi Function Displays
Raymarine Radar
Raymarine Fish Finder/CHIRP sonar
Raymarine Augmented Reality RVX - 3d real vision
Raymarine Radar
ABT Trac Digital stabilizers with Digital panel at helm station and remote at flybridge
Furuno GPS Navigator
ICOM IC-M323G GPS VHf radio w. Distress Call
ICOM VHf M330GE radio. Aug. 2021
ICOM MF/HF M710 Transciever
ICOM IC-M505 VHf at flybridge helm station
FLIR night vision camera system
Dual Robertson AP22 autopilot controls at flybridge
Rudder Angle Indicator
Schatz Stainless Ships Bell Clock
Schatz Stainless Precision Barometer
Forward and reverse cameras
Engine room cameras
Deck Gear
ARITEX stainless steel hydraulic-electric davit with wired remote
Roll prevention at anchor with Flopper Stopper rigs port and starboard
Outdoor shower on aft deck
Saltwater deck washdown
2 stainless ventilation dorades
Two foredeck lounging cushions
New wiper blade arms and blades July 2021
Windshield wash system on front wheelhouse windows
Swim ladder
Southern Stainless steel BBQ mounted on fly bridge with two stainless steel gas bottles (certified April 2022)
Boat deck hinged hatch over aft cockpit ladder
Spotlight - ARC
6 storm plates for the port and starboard salon windows w/ custom storage rack
60lb Fortress stern anchor with chain and line
Chain stopper
Hydraulic Anchor Chain wasdown pump
Spare portable fuel tanks
Pilot House boarding, port and starboard for access from high quays or jetties
4 x dive bottle racks in bow locker
Spare Fortress anchor - folding
Custom fixed bimini over flybridge
Clears front, sides and aft of flybridge cockpit. New 2021
Stern capstan - Maxwell 2200 electric snubbing winch
2 x Glenndenning shore cord systems at stern, each with 100' of cable
Teak decks on cockpit, side decks and swim platform
Dual Pompanette seats on flybridge
Exterior floodlights (2 total) one on upper deck, one on lower deck
6 x New 25mm mooring lines, 4 x white fenders
Combination safe
2 spare main engine propellers stored/mounted in lazarette
