62 Nordhavn 2004 Yacht for Sale

Length Overall 20.40 m / 67’ 0”
Length at Waterline 16.92 m / 55’ 6”
Max Beam 5.90 m / 19’ 4”
Draft 2.10 m / 6’ 9”
Displacement 155,000 lbs / 70.31 MT

CE Category 'A' Ocean
MCA coded

SALOON
- Large saloon seating area
- New larger salon windows
- Bose Lifestyle 35 stereo system with DVD player (5 speakers and subwoofer).
- Airtex TV lift with Panasonic 42’plasma television to port
- Nutone central vacuum system

GALLEY
- Danby II wine cooler
- GE trash compactor
- Granite counter top
- Miele 18” dishwasher
- Additional AC outlets in galley
- Instant hot water dispenser
- Asko washing machine
- Asko drying machine
- Granite cabin sole
- 2 x Sub-Zero Refrigerators – Model 249RP
- Sub-Zero Freezer 245, with ice maker
- GE microwave/convection oven
- GE electric 4 burner hob
- GE convection oven
- In sink garbage disposal

OWNERS SUITE
- Custom mattress
- Mirrored headboard with teak frame and full length mirror on bulkhead
- 17” Phillips HDTV & DVD player
- Owners safe
- En-suite bathroom with Grohe fixtures in sink and shower.
- Granite counter top with white sink
- Magnum Opus heads with fresh water flush
- Grohe soap dispenser at the sink

GUEST CABINS
- Port cabin has double berth with custom mattress
- Forward cabin has double berth
- Starboard cabin has upper & lower bunks

GUEST EN-SUITES
- Grohe fixtures in sink and shower
- Upgraded shower doors for all 3 guest head showers
- Granite counter top with white sinks
- Magnum Opus heads with fresh water flush
- Grohe soap dispenser at the sink

PILOTHOUSE
- Teak and spruce sole
- Cabinets & panelling in varnished teak
- Dinette table in teak with high gloss varnish
- Norcold Refer with ice cube tray freezer
- Stidds Low Back “Admiral” helm seat
- 8” Perko 1000 watt spot light

1 X JOHN DEERE 6125 AFM1 340HP DIESEL ENGINE

- Electronic control system
- Dry exhaust and keel cooling system for main
- Twin disc electronic controls for main engine with stations at pilot house, and cockpit console
- Portuguese bridge with port and starboard controls
- John Deere 4045 DSM 85hp wing engine, with Martec propeller and PTO for hydraulic pump.


[“Get Home” power is a major concern for those venturing to far off places, and Nordhavn again gives this area special attention.
Each 62 is equipped with a separate 4-cylinder wing engine that drives a feathering prop.
The boat can be driven in open ocean conditions and is perfectly capable of being brought home if the main engine is disabled. The wing
engine is installed with its own electrical system and is used to power the hydraulic systems for the bow thruster, windlass and emergency
bilge pump system]

- new fischer panda generator
- 25HP hydraulic bowthruster, with 4 control stations
- 25HP hydraulic stern thruster with 4 control stations

- ABT TRAC #254 stabilizers with 9 SQ Ft fins and digital controls

- Dual Racor filter system for the main engine
- Combination fuel transfer and polishing system
- Spurs rope cutter on main engine shaft

- New and used lube oil tanks, with oil change system for main, wing and generator
- New oil tank is 50 gallons
- Used oil tank is 200 gallons
- Accu-steer(2) HPU-150-12 auto pilot pumps installed
- Sea chest distribution system (FRP) with two independent thru hulls and strainers

- Air conditioning throughout the yacht – 7 air handler zones operated by 6 remote mounted compressors with SMX controls
- 240v air conditioning pump with its own sea chest inlet and switchsystem
- Spare AC pump

- Fire suppression system in engine room with auto shut down system
- 180 gpm Emergency bilge pump to 3 watertight compartments
- Village Marine 800 gal per day water maker (with fresh water flush, UV sterilizer and remote control panel)

- Fresh water pumps:
120v Headhunter pump
12v back up water pump
3 x electric bilge pumps
3 x manual bilge pumps

Universal Electrical system – enables vessel to operate on 240v 60hz,120v 60hz or 230v 50hz.
- 2 x 4024 (24v) inverters with series stacking option for a total of 8 KW of inverter power
- Charles 12kw isolation transformer
- Charles 60 amp 24v charger (operates from 50 or 60hz)
- Electrodyne 250 amp 24V alternator-hydraulically driven from main or wing engine
- Leece-Neville 200ah 12v alternator-belt driven from the main engine

- 2 x 50 amp 60’ 120/240 shore power leads
- 12v wires to Windlass area for use with back-up DC Windlass motor

DECK & GEAR
- Besenzoni passerelle (hydraulic), with remote control
- Maxwell 3500 HWC windlass
- GPM anchor chain wash system
- 400ft 1/2” HT chain
- 300 LB Airtex stainless steel Plough anchor
- Spare anchor – 75 lb Danforth

- Upgraded Airtex deck crane, with 1,000 KG capacity
- Flopper stopper (antiroll device) for use at anchor
- Maxwell 12 VDC Capstan winch in cockpit

- Raised aft deck entertainment area, incorporating seating with cushions, storage, tables, awning and built in overhead lighting
- Custom built dinghy chocks & davit crutch
- Boarding ladder
- Fishing rod holders installed on cockpit cap rail
- Gasoline storage tank (aluminium) in the starboard foredeck box – approx 40 gallons
- 12 VDC demand pump installed

- Miele electric cockpit BBQ, with folding SS cover
- U-Line Icemaker installed on the aft deck
- Stainless steel horn
- 16’ (5.1 m) Rendova hard bottom inflatable & 115hp Yamaha outboard
- Bimini top cover
- Fresh water shower
- Swim ladder

SAFETY EQUIPMENT
- ACR EPIRB with built in GPS
- 2 x 8 man lift rafts
- Fire extinguishers and first aid kit

1•New seacocks fitted

2 New batteries installed

3 New holding tank hoses

4 New hose on Air-con system

5 New Fischer Panda generator installed

6 New main engine shaft

7 New cutlass bearing main engine/wing

8 Prop rebalanced

9 New anodes 1

10 New bilge pumps

11 New oil cooler on wing engine

12 New water tank gauge in pilot house 1

13 New fuel tank gauges installed in pilot house 1

14Wash out all fuel tanks

15 New lift hose on stainless steel tender crane

16 New Victron inverter charger runs on 120V/240

17 New solar panels charger system providing 44 amps 1

18 New hydraulic cooling pump

19 New bow thruster/stern thruster solenoids 2

20 New blue under water lights

21 New hydraulic oil cooler added to main engine

22 New drinking water pump with a back up system fitted

23 New domestic hot water tank fitted with immersion heater 2

24  New hot water linked to engine so hot water generated when engine is running

25 New led light bars fitted on main deck along with LED lights in boat

26 2 x new life rafts

27 New on board air compressor fitted

28 Air-con & heating re gas

29 Air-con electric cards all serviced

30 Air-con & heating systems serviced

31 New engine room lights

32 New rudder indicator gauge fitted in pilot house

33 New main engine hydraulic pump seals

34 New depth transponder fitted

35 New wing engine water pump

36 Fuel lines washed out

37 New exhaust hose fitted

38 Exhaust bend 90 replaced

39 New washing machine

40 Custom made interior panels installed along with all new roof linings and upholstery.

41 Oil changed on hydraulics

42 Old antifreeze removed and new added

43 Exhaust silencer replaced

44 New exhaust gaskets

45 New exhaust lagging

46 Head vacuum pump reconditioned with new motor and new shaft.

47 Hydraulic oil keel cooler serviced

48 Main engine antifreeze keel cooler tested and good

49 Hydraulic alternator replaced

50 New hydraulic switch’s fitted

51 New Furuno radar system with 3 oversized screens fitted along with time zero max sea professional.

52 New Hik vision CCTV system fitted working from mobile device also

53 New VHF

54 AIS added

55 Internet added to boat

56 New Intellian Tv satellite dome installed

57 Bose sound system

58 New fusion audio system fitted

59 wood work for cluster in pilot house

60 New fenders and mooring lines

61 On board weather forecasting system fitted and pilothouse wiring replaced.

62 Hull blasted and anti-fouled October 2022

Furuno TZT19F Time Zero Touch 3  x 19” Inch Display

Experience navigation like never before with this stunning and powerful 19" Multi Function Display. Imagine having one or multiple units on your helm, giving you a conning station with flexible displays. TimeZeroTM technology is faster than ever before

NavNet TZtouch3 incorporates a fast quad-core processor so you can scroll, pan, and zoom in/out completely smooth & seamlessly. Plus, you can navigate in a 3D environment, offering you a realistic perspective and an expanded view of the area around your boat. The 3D chart perspective is perfect for planning and navigating routes.

MapMedia Vector & Raster Chart Library

Freely choose the charts that fit your individual needs. MapMedia brings an extensive library to your NavNet TZtouch3 and makes it easy to select raster, vector or fishing charts. C-MAP as well as “Datacore by Navionics” vector cartography are optional charts that can be easily unlocked. MapMedia cartography integrates cutting edge algorithms with high-resolution image processing techniques to deliver a fusion of digital navigation charts and satellite photography.

24VDC Ethernet Hub

 Radar

Furuno DRS4D-NXT Solid State Radar

New Solid-State Radar using Compressed Pulse Technology for outstanding target detection at ranges up to 36NM. Includes Furuno’s new Target Analyser which automatically changes the colour of targets which are coming towards the vessel at more than 3 kts. Up to 100 (ARPA) Targets, Doppler Processing, Dual Range and Chart Overlay.

Furuno DRS6A-NXT Solid State Radar with 4ft Open Scaner

New Solid State Radar using Compressed Pulse Technology for outstanding target detection at ranges up to 36NM. Includes Furuno’s new Target Analyser which automatically changes the colour of targets which are coming towards the vessel at more than 3 kts. Up to 100 (ARPA) Targets, Doppler Processing, Dual Range and Chart Overlay.

Furuno SC-70 Satellite Compass

Heading information for radar, Scanning Sonar, Video Plotter. Same performance as a Gyro Compass. Works as a normal GPS navigator. Heading Accuracy of ± 1o complying with IMO MSC.116(73) as a Transmitting Heading Device. Pitch and Roll output in both analogue and Free from routine maintenance. Supplied with 15m antenna cable.

Basic N2K Kit

Class B AIS Transponder

c/w with GPS Antenna for AIS

CX4 VHF Antenna for AIS with Bracket

New Icom VHF
