100 Custom 2014 Yacht for Sale

                                         DESCRIPTION & PARTICULARS

VESSEL NAME:

RIO 100

VESSEL TYPE:

BAKEWELL-WHITE 100 Supermaxi,

YEAR VESSEL BUILT & HULL NUMBER

2003/2015

DESIGNER:

Brett Bakewell-White

BUILDER:

Hakes Marine

DIMENSIONS:

BEAM

DRAFT

DISPLACEMENT

27,170 KG

GENERAL CONSTRUCTION:

Composite carbon / Nomex sandwich

PROPULSION ENGINE:

Yanmar Diesel

ON BOARD ELECTRICAL SYSTEMS:

12 v DC

Dimensions, weights, speeds and capacities are reported, not measured.

HULL, DECK, JOINERWORK & APPENDAGES

HULL:

Shape: Round bilge, ULDB

Construction: Unidirectional Carbon and S-glass/PVC foam core/AME 4000 Modified Epoxy resin

Frames: S-glass/PVC foam/Epoxy vacuum bagged

Main Bulkheads: Marine grade Plywood encased in E-glass

Structural Bulkheads: E-Glass faces/Foam core/ Carbon capping

Interior Finish: Matterhorn White LP

Exterior Finish: Flag Blue LP w/ custom highlights & graphics

DECK:

Construction: Unidirectional Carbon & S-glass/PVC foam core/Epoxy resin

Interior Finish: Matterhorn White LP

Exterior Finish: Snow White LP smooth areas w/ Matterhorn White LP contrasting non-skid surface

JOINERWORK:

Joiner Bulkheads are E-glass/Foam composite

Cubbies/bins and countertops are E-glass/Foam composite

Cabin Sole is Composite Panels w/ Teak & Holly Veneer

APPENDAGES:

Keel Fin: Bronze Fin fabricated by Industrias Duro

Keel Bulbs: Lead Bulbs fabricated by Industrias Duro (Transpac & IRC)

Spade Rudders: Carbon Fiber rudder shaft and blade fabricated by Advanced Composites Concepts ( Both new in 2018)

INTERIOR ACCOMMODATIONS

HEAD: (Centerline)

Enclosed Compartment with separate Shower stall

Sink w/ Vanity

SHEET STOWAGE & HANGING LOCKER: (Port and Stbd side forward of mast)

Sheet Stowage Bar

Foul Weather gear bars P&S between Main Bulkheads

SALON:

Settee to Port & Pilot Berth Outboard

GALLEY: (Starboard Side)

Carbon deep sink

Gimbaled stainless steel, LPG Force 10 stove with (3) burners & Oven (New 2014)

Refer/ Freezer / Food Lockers outboard

NAVIGATION STATION: (Centerline)

Benchstyle station w/ aft seat access to Nav. Table

Instruments & Breaker panel along hull

Stowage beneath and outboard of seats

AFT: (Port & Starboard Side)

Pipe Berths with lift tackles (Upper & Lower)

INTERIOR CUSHIONS:

Grey

INTERIOR FINISH:

Flat surfaces Painted Matterhorn White and Black LP

Clear coat carbon counter tops

MECHANICAL SYSTEMS

ENGINE:

Yanmar 4 cylinder 75 hp diesel marine engine (1371 hours)

Hydraulic drop down drive

Three-blade prop 21 x 15

Engine instrument Panel w/ RPM & warning lights and buzzer alarms

150 amp high output alternator (Spare carried onboard)

FUEL SYSTEM:

250 liter Polyethylene fuel tank

750 liter polyethylene delivery tank(removable)

Racor in-line fuel filter

REFER/FREEZER

Fridgetech mechanical driven fridge and freezer

Carel electronic controller

LPG SYSTEM:

LPG plumbing and shutoff system

BEP series 600 Gas Detector

LPG Tank locker on deck aft for one tank

LPG Tanks 2.5lbs

FIRE PROTECTION:

Hand held type B-1 USCG approved fire extinguishers

STEERING:

Custom McConaghy twin wheel installation

Offshore pedestals with compass P&S

Offshore type with double cables

Carbon steering arms and tillers

Harken alloy track and car steering system

ELECTRICAL & PLUMBING SYSTEM

ELECTRICAL SYSTEMS:

24 Volt Mastervolt Li-ion MLi Ultra 24/5000

12 volt DC 85 amp engine start battery

LED Chart table light

LED red and white lighting throughout

LED floor lighting

Engine Battery Switch

House Battery Switch

Parallel Battery Switch

DC Circuit Breaker Panel

12-volt DC cigarette lighters

Mastervolt Chargemaster 24/60-3 Battery Charger

Mastervolt 24 volt to 220-volt inverter

Mastervolt C-zone Digital control and monitoring system

220 volt power outlet in galley

NAVIGATION LIGHTS:

Carbon Lopolight LED Masthead Tri-color/Anchor light

Hella LED Stern light

FRESH WATER SYSTEM:

24 volt DC pressure water

Cold water spigot @ Galley sink

Cold water spigot @ Head sink

Hot water spigot @ Head shower

Hot water spigot @ Galley

Hot water spigot @ shower

40 gallon polyethylene water tanks 2 port, 2 starboard

40 liter hot water heater

Spectra Capehorn Watermaker

SEAWATER SYSTEM:

Hand Pump w/ filter (Galley sink)

SINKS

Carbon Galley sink

Carbon Head sink

BILGE PUMPS:

Manual WhaleGusher pump (cockpit)

Manual Whale/Gusher pump (below decks)

NAVIGATION ELECTRONICS

SAILING INSTRUMENTS:

B&G Hercules 3000 system w/ processor & software upgrade

B&G Sensors

Load cell

Wind

Boatspeed

Depth

Fluxgate Compass

Barometric pressure

Heel

Brooks & Gatehouse Displays

Full Function Display (FFD)

Wind

20/20

40/40 mast displays in Carbon pod

Hydra FFD display on each binnacle

NAVIGATION:

Leica MX420 Navigation System

B&G ZEUS Touch GPS

Deckman Tactical software

Suunto Compass pedestal mounted

COMMUNICATION:

ICOM VHF Marine Radio

ICOM SSB

Iridium GO

Pepwav modem and Yachtrouter

Standard Horizon VLH-3000 Loud Hailer with a speaker on each steering ped.

MISCELLANEOUS:

JVC KD-X310BT Stereo System

Stereo Speakers (deck)

Stereo Speakers (salon)

Spare Wind Instrument wand & cable

Spare Boatspeed Transducer

DECK GEAR

HARDWARE & FITTINGS:

Transverse adjustable harken Roller Bearing athwartship jib tracks

Harken Halyard Stand-up Blocks

Spinlock Pit Jammers

Lewmar aft hatch

Harken roller bearing main traveller

Harken Running Backstay flying blocks

Harken Running Backstay deck blocks

Harken Spinnaker Blocks

Lewmar opening cockpit port lights

WINCHES:

Primary winches

Mainseet winch

Utility/Halyard winch

6-man overdrive box, 1:2

Runner winches

port counter rotating

Halyard winches

990 STAE 3 speed, self-tailing, carbon top jaw, solid housing, electric

B990 control box

BRS104P Switch

HCP Circuit breaker

Traveler winches

Pedestal system (all Harken)

Pedestal 2 Carbon below deck, 2 disconnects

Pedestal 1 Carbon below deck, 1 disconnect

Pedestal 0 carbon below deck, 0 disconnects

601 Bevel 6 man bevel box

601T/vertical disconnect 6-man T-box w/vertical disconnect-mainsheet

Carbon vertical support system 839406 xbox

600 X/3 disconnect 6 man X-box w/3 disconnects to runner pedestal

Carbon drive shaft w/coupler

Carbon drive shaft w/u joints

842260 Disconnect buttons

842349 Remote disconnect buttons

431835 Tensioner for remote button

43185 Preselector for overdrive

HYDRAULICS: All Cariboni

5 Function Cariboni Panel in forward face of mainsheet pod

5 Function Cariboni panel port and starboard trim area

Outhaul cylinder in boom

Vang

Jib tack

Jib clew up/down

J5/GS tack

Mid prod tack

Cunningham

Checkstay

Backstay

Cariboni rotary pump w/overdrive

All hydraulics can be operated by the power pack, hand pump and rotary pump

LIFELINES & PULPITS:

Double lifelines w/ Stainless Steel stanchions

Stainless Steel double rail, welded, bow pulpit

Stainless Steel double rail, welded, stern rails

MISCELLANEOUS:

Harken Snatch Blocks

Snatch Block slider Cars

SPARS & RIGGING

MAST:

Southern Spars Pre-preg carbon fiber laminate with harken track and 5 garages for reefs Five sets of tapered carbon airfoil section spreaders

Carbon masthead with attachments for headstay, backstay and 2:1 main halyard.

Two Spinnaker halyards with chafe guards and rollers (port and stbd) w/ deck     controlled locks.

Two Genoa halyards with chafe guard w/deck controlled locks

Fractional halyard w/chafe guards and deck controlled lock

J5/GS halyard with deck controlled lock

Halyard exits to suit deck layout

Checkstay deflector system exiting below deck to hydraulic ram

Cunningham lead thru gooseneck boom ferrule exiting below deck to hydraulic ram

Lightweight boom vang and gooseneck attachments.

Mast step slider plate to suit mast heel and boat.

Mast heel with 2.5m radius to suit hydraulic jack system and WS Special Regs.

Instrument bracket, masthead VHF, instruments and cables fitted. Internal cables enclosed in protective braided sock.

Clear Awlgrip finish with contrasting bands at “P” and “E” limits.

BOOM:

Hall Pre-preg carbon section

Outhaul control by hydraulic cylinder in boom.

Sheaves for outhaul & threereefs with two stoppers at forward end of boom.

Mainsheet attachment strap

Clear Awlgrip finish with contrasting bands at “P” and “E” limits.

STANDING RIGGING:

V1                                     C6                                                             (2)

D1                                    C6                                                             (2)

D2                                    C6                                                             (2)

D3                                    C6                                                             (2)

D4                                    C6                                                            (2)

D5                                    C6                                                             (2)

Catherdal                            C6                                                                   (2)

Headstay                          C6                                                                   (1)

Checkstay          T              Aramid                                                      (2)

Running Backstay        T              Aramid                                                      (2)

Backstay                           Aramid                                                              (2)

HALYARDS: (All halyard and reefing control lines lead aft to pit)

Main halyard                               12mm Dynema

Spinnaker halyards                      14mm Dynema

Jib Halyard

One (1) topping lift/staysail halyard        10mm Dynema

Reef Line                           14mm Spectra

RUNNING RIGGING:

Jib sheets with eye splice for T clew

Spinnaker Sheets

Misc sheets

SPARES:

Halyards

Spinnaker Halyards

SAFTEY GEAR:

Emergency Rudder System (Custom alloy cassette and carbon fiber blade)

GROUND TACKLE:

Fortress anchor w/ chain & Poly rode

CQR 35lb. anchor w/ chain & Poly rode

CANVAS/VINYL COVERS:

Mainsail Cover

Deck Covers

Cockpit Sheet bags

MOORING EQUIPMENT:

Heavy Duty Dock Lines (long)

Heavy Duty Dock Lines (short)

Extra Large inflatable Fenders w/ covers

Large Fenders

ACCESSORIES

SHIPPING:

Keel Cradle & pallet

MISCELLANEOUS;

Ship’s ensign and carbon staff

Ship’s papers and manuals

Emergency tiller

150 amp high output alternator (Spare carried onboard)

SAIL INVENTORY

RACING INVENTORY:

Sail                                         Make                                      Year

2 reef Mainsail Doyle 2014

2 reef Mainsail Doyle 2020

J 0 headsail Doyle 2019

J- 2 Doyle 2020

A 1.5 Doyle 2023

A-2 Doyle 2020

A 2.5 Doyle 2023

A -3 Doyle 2020

A-4  2020

J 5 Doyle 2019

J 5 Doyle 2023

AP #1 Doyle 2014

J4 Doyle 2014

#5/GS Doyle 2014

# 5 GS Doyle 2023

Drifter Doyle 2014

FR0 Doyle 2014

R-1 Evolution 2011

R-1 Doyle 2020

R-2 Doyle 2014

R-3

A1.5 Doyle

Doyle 2014 A-2

Doyle 2014 A-3

North 2016 A-4

Doyle 2014 A4-B

Doyle 2013 A6

Doyle 2020 A-6

North 2012

SS Doyle 2017

SS Doyle

Storm Jib Doyle 2014

UPGRADES LOG

Hull and deck Aft half of hull cut off New aft hull section fabricated Purchased twin rudders from Farr 80 Beau Geste Twin rudder configuration added New upper and lower bearings from JP3 Purchased keel fin and bulb from Beau Geste Monolithic keel box fabricated to allow keel to be hydraulically raised and lowered

Custom kelp cutter on keel New keel floors New aft deck section fabricated Wheels moved aft Forward grinders moved outboard  Structural deck chocks removed and replaced by under deck stringers 8 bulkheads modified to accept wider hull 10 new bulkheads fabricated  New transom and chainplates for runners and topmast Existing longitudinals lengthened  2 new longitudinals added to strengthen new hull shape Existing hull completely sandblasted to remove fairing and bottom paint Re fair existing hull section Repair damaged stanchion pockets Jib tracks removed side deck reinforced, jib tracks re installed New helm foot chocks

LPG locker added

4 custom LPG bottles

Sushi rails added aft of pedestals (2) 16 stack pockets added Aluminum stacking posts (10) New prod fabricated and installed Deck lights added for head and shower New SS stanchions x 28 Harken rotary hydraulic pump Cabin house windows removed and replaced with foam inserts Steering hubs replaced to lower turn ratio B & G MFD's added at each steering pedestal Lewmar ports added in cockpit (4) Winch system refurbished and upgraded where necessary Port runner winch re geared to make it anti clockwise Deck painted and non skidded Hull primed and painted New emergency rudder Custom carbon rudder cassette for emergency rudder Custom alloy pintels for emergency rudder New rudders (2) and new JP3 bearing (1 set)

Interior New Galley Deep carbon sink 3 burner/oven Force 5 stove New LPG system Custom Fridgetech reefer and freezer with digital control 220 volt outlet 220 volt tea kettle Aluminum sushi rail Custom carbon trash bin Storage bags located throughout

 New cushions in settee area New enclosed shower with hot and cold pressurized water New enclosed head with hot and cold pressurized Water ballast tanks removed New plumbing New wiring throughout New Yanmar diesel engine New polyethylene fuel tank(2) 1 250 liter day tank 1 750 delivery tank removable Hydraulic systems upgraded New power pack for hydraulic functions Complete refit of navigation station area New 24" color monitor New VHF New B & G GPS New ICOM on deck comms JVC radio with 4 speakers  C-zone system for energy monitoring

New master volt lithium ion 24 volt batteries x 2 Mastervolt 24/220 inverter  New Spectra Cape Horn water maker w/custom scoop through hull New 40 liter hot water heater New hot and cold pressurized freshwater system New LED lighting throughout  Fans in each bunk, nav station and galley New floorboards Custom SeaDek flooring in all aft bays New bunks and squabs (18) New freshwater tanks (4) Custom personal storage/gear bags throughout  Custom vinyl graphics in working area  Rig and rigging Mast unstepped, ultrasounded 10 ton lock added for J5 New carbon masthead wand New cabling (B & G, VHF, lights) Mast and spreaders painted New Hall spars boom New runners, check stays and topmasts from Southern Spars Headstay sent to Future Fibres for inspection and re-covering Mast and boom ultra sounded All standing rigging sent to Future Fibers for inspection and recovering

Cradle Cradle sandblasted, reinforced and coated by Noakes in Australia as per shipping company in order for shipment from AUS to USA
